The 9F206-02 Configuration Screen
The 9F206-02 ConÞguration Screen (Figure 2), displays conÞguration and status
information about the 9F206-02 Module.
Module Name:
Slot Number:
FNB-1
Port A Status:
Port B Status:
External Path:
Configuration:
FNB-2
Port A Status:
Port B Status:
External Path:
Configuration:
SAVE
SMARTSWITCH 9000 LOCAL MANAGEMENT
9F206-02 CONFIGURATION
9F206-02
12
Status: Wrap-A
Link
Link
Primary
Inserted
Status: Wrap-A
Link
Link
Primary
Inserted
Figure 2. 9F206-02 Configuration Screen
9F206-02 Module Specific Information
Firmware Revision:
BOOTPROM Revision:
DAS-1 Status: Dual Homed
Port A Status: Link, A-M
Port B Status: Link, B-M
Port A Type: FPIM-00
Port B Type: FPIM-00
DAS-2 Status: Isolated
Port A Status: No Link
Port B Status: No Link
Port A Type: FPIM-00
Port B Type: FPIM-00
02.00.01
01.01.02
RETURN
