Zaxcom ZMT3 Phantom 2

TRANSMIT MENU

UHF Transmitter Power Level Set

TX POWER: 50MW
The UHF transmit power of the ZMT3 Phantom 2 is set from this page. The transmit power can be
adjusted to output 25, 50 or 75mW. The higher the power setting the more battery power will be
required.

UHF Transmit Modulation Set

TX FORMAT:
ZHD96
PRESS CARD TO REBOOT
The UHF transmission modulation is the way the ZMT3 Phantom 2 sends audio to the receiver. The modulation
format is set from this menu. Please note if the transmission format that is set here, and the format set on the
receiver do not match, the receiver will be unable to decode the audio from the transmitter. Also note that
after any change to the transmit format the ZMT3 Phantom 2 will need to be rebooted by pressing the card key
before the new format takes effect.
Modulation Bandwidth
Minimum Channel to Channel Spacing
6 MHz TV Channel Capacity
Latency
Compatibility with a 200 Series Receiver
Compatibility with a 300-96 Receiver
Compatibility with a 300-48 Receiver
* When used with a QRX300-96 receiver – the minimum spacing is 300 kHz when using all other receivers.
**When used with a QRX300-48 receiver – the minimum spacing is 200 kHz when using all other receivers.

Transmitter Disable - Record only mode

TX DISABLE :
NORMAL TX MODE
Record Only Mode - Will set the ZMT3 Phantom 2 to act as a standalone recorder and will not transmit any
•
audio over UHF. This will conserve battery power since the transmitter is disabled.
Normal TX Mode - Will allow the ZMT3 Phantom 2 to both transmit audio and record on its internal micro SD
•
card.
MONO XR
200 kHz 200 kHz
400 kHz 400 kHz
15 15
3.5ms 6ms
2 Transmitters 2 Transmitters
NO NO
NO NO
11
Transmit Menu
ZHD 96 ZHD 48
96 kHz 48 kHz
200 kHz* 100 kHz**
30 60
6ms 18ms
2 Transmitters 1 Transmitter
1 Transmitter 1 Transmitter
NO 1 Transmitter
