TRANSMIT MENU

UHF Transmitter Power Level Set

TX POWER: 50MW
The UHF transmit power of the ZMT3-HH is set from this page. The transmit power can be adjusted to
output 25, 50 or 75mW. The higher the power setting the more battery power will be required.

UHF Transmit Modulation Set

TX FORMAT:
ZHD96
PRESS CARD TO REBOOT
The UHF transmission modulation is the way the ZMT3-HH sends audio to the receiver. The modulation format
is set from this menu. Please note if the transmission format that is set here, and the format set on the receiver
do not match, the receiver will be unable to decode the audio from the transmitter. Also note that after any
change to the transmit format the ZMT3-HH will need to be rebooted by pressing the card key before the new
format takes effect.
Modulation Bandwidth
Minimum Channel to Channel Spacing
6 MHz TV Channel Capacity
Latency
Compatibility with a 200 Series Receiver

Transmitter Disable - Record only mode

TX DISABLE :
NORMAL TX MODE
Record Only Mode - Will set the ZMT3-HH to act as a standalone recorder and will not transmit any audio
•
over UHF. Please note the XLR output will still be active. This mode will also conserve battery power since the
transmitter is disabled.
Normal TX Mode - Will allow the ZMT3-HH to both transmit audio and record on its internal micro SD card.
•
MONO XR
200 kHz 200 kHz
400 kHz 400 kHz
15 15
3.5ms 6ms
2 Transmitters 2 Transmitters
11
Transmit Menu
ZHD 96 ZHD 48
96 kHz 48 kHz
200 kHz* 100 kHz**
30 60
6ms 18ms
2 Transmitters 1 Transmitter
