ZAXNET MENU

ZaxNet Mode

ZAXNET MODE: TX
This menu sets the mode of the ZaxNet transceiver.
OFF - The ZaxNet transceiver is disabled. The ZMT3 Phantom 2 will not receive ZaxNet commands or time
•
code and it will not send any ZaxNet audio. Please note if ZaxNet mode is set to OFF the several ZaxNet
menu items will not appear.
RX - The ZaxNet transceiver will receive ZaxNet commands and time code.
•
This screen will display what ZaxNet data is being received by the ZMT3 Phantom. Including total received
information packets, ZaxNet TC received and remote control commands received. This information is used
for debugging purposes.
TX - The ZaxNet transceiver will send ZaxNet confidence audio and time code. Please note that in ZHD48
•
mode the ZMT3 Phantom 2 will not be able to go into transmit mode.

ZaxNet Receive Frequency Set

This menu will only appear if ZaxNet is set to receive (RX) mode
RX FREQ : 2.403 RX
SIGNAL : 28
The ZaxNet receive frequency is the frequency that the ZMT3 Phantom 2 will get its wireless time code and
remote control commands on. This frequency will need to match the frequency of the corresponding ZaxNet
transmitter. The ZaxNet transmitter can be a QRX with QIFB, Nomad, TRX900CL or IFB100/200. The ZMT3
Phantom can also receive ZaxNet time code from another TRX / ZMT3 transmitter or a ZFR recorder that is
transmitting ZaxNet on this frequency. Please keep in mind that the range will be limited when receiving
ZaxNet from a TRX or ZFR.
When the ZMT3 Phantom 2 is receiving a valid ZaxNet signal the signal strength will be shown as well as signal
strength meter that runs vertically on the far right side of the screen.

ZaxNet Transmit Frequency Set

This menu will only appear if ZaxNet is set to transmit (TX) mode
ZAXNET TX FREQ:
2.473
The ZaxNet transmit frequency is the frequency that the ZaxNet transmitter on the ZMT3 Phantom 2 will
broadcast time code and confidence audio on. Please note the ZaxNet transmitted audio is for quality control
purposes and the expected range will be less than 20 feet.
