TRANSMIT MENU

UHF Transmitter Power Level Set

TX POWER: 50MW
The UHF transmit power of the ZMT4-X is set from this page. The transmit power can be adjusted to
output 10 or 50mW. The higher the power setting the more battery power will be required.

UHF Transmit Modulation Set

TX FORMAT:
ZHD96
PRESS CARD TO REBOOT
UHF transmission modulation is the way the ZMT4-X sends audio to the receiver. The modulation format is set
from this menu. Please note if the transmission format that is set here, and the format set on the receiver do
not match, the receiver will be unable to decode the audio from the transmitter. Also note that after any
change to the transmit format the ZMT4-X will need to be rebooted by pressing the card key before the new
format takes effect.
Modulation Bandwidth
Minimum Channel to Channel Spacing
6 MHz TV Channel Capacity
Latency

Transmitter Disable - Record Only Mode

TX DISABLE :
NORMAL TX MODE
Record Only Mode - The ZMT4-X to act as a standalone recorder and will not transmit any audio.
•
This will conserve battery power since the transmitter is disabled.
Normal TX Mode - The ZMT4-X to both transmit audio and record on its internal micro-SD card.
•
STEREO
MONO
200 kHz 196 kHz
400 kHz 200 kHz
15 30
3.5ms 6ms
11
Transmit Menu
XR ZHD 96
200 kHz 96 kHz
400 kHz 300 kHz
15 30
6ms 6ms
