Advanced Functionality; Saving A Position - LOGICDATA LogicS-2 User Manual

User Manual
LogicS-2 / LogicS-3

4.2 Advanced Functionality

Note: Functionality described in this chapter is only accessible if you
have a handset with position keys and a save key!

4.2.1. Saving a Position

This function allows to save one desk-height per position key. To save a desk
position, proceed as follows:
Note: On initial operation all stored positions are equal to the lowest
possible desk-height (lower end position).
1. Move the desk to the position you want to save.
The display reads the actual height of the desk (e.g. 73cm).
2. Press the S key.
The display reads S –.
3. Press the desired position key (e.g. T2).
The display reads S 2.
4. Now the height is saved on the chosen position key .
The saving operation is confirmed with a double-click sound and
after appr. 2 seconds the stored height will be displayed.
Note: The position keys may have varying design, depending on the
kind of handset used.
Page 17/33
