User Manual
LogicS-2 / LogicS-3
6. Fix the mounting plate with 2 screws in the pre-drilled holes.
Fig.3 - Step 6
Note: Note the V formation of the mounting plate (see fig. 3)!
7. Slide the LogicS control box onto the mounting plate so it is fully inserted in the
control box housing.
Fig.4 - Step 6
8. Mark the drill holes in the mounting link with a pencil.
Fig.5 - Step 8
Page 11/33
