Technical Specifications

2. Technical Specifications
Electrical Characteristics
External Power Supply
Operating Voltage Range
Input Current
Backup Batteries
Display
PGM Open Collector Output
Local Siren
Communication (RF) Characteristics
Frequencies
RF Jamming Detection
Anti-collision
Programmable No-activity Timer
Reporting
Telephone and Modem
Environmental Characteristics
Operating Temp. Range
Storage Temp. Range
Operating Humidity
Dimensions
Height x Width x Depth
Weight
HLX-24 User Manual
220 VAC/50 Hz, 110 VAC/60 Hz
15 VDC, 800 mA
Standby: 150 mA
Max: 300 mA
4 AA (1800 mAh rechargeable batteries are
included)
Two Line, 16 characters, white backlit LCD
100 mA, PTC protected
87 dBA @ 1 m (3.28 ft)
433.92 MHz (G version)
868.35 MHz (H version)
UL/EN selectable
Proprietary RF protocol
1–30 minutes, per zone
Three private telephone numbers.
Built in dialer & 2400 Baud modem
0ºC to 60ºC (32ºF to 140ºF) without battery
0ºC to 45ºC (32ºF to 113ºF) with battery
-25ºC to 70ºC (-13ºF to 158ºF)
0 to 85% at 30ºC non-condensing
174 x 152 x 48 mm
(8.5 x 5.7 x 1.9 in.)
330 g (11.6 oz)
