Mocka Nava Three Drawer Assembly Instructions Manual page 6

Nava Three Drawer
Assembly Instructions
9
L
Q
U
10
11
U
3 11
Attach Legs [11] to panels [10] with 4x washers (L) and 4x bolts (Q).
Tighten with the Allen key (T). Attach 4x plastic glides (U) to the
legs using a hammer as shown.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
U
3 11
U
3 10
3 10
T
L
Q
3 10
10
3 11
Slide panel [7] down along the grooves between the panels [3] and [4].
7
3
4
6
