- Page 1 AG14005 ASSEMBLY INSTRUCTIONS ASSEMBLY HANDY ANDY INSTRUCTIONS ALUMINUM GATE AG14005 60 MIN Approximate assembly time Want to see a video on how to assemble this product? Scan the QR code WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM VER. 060821...
- Page 2 AG14005 ASSEMBLY INSTRUCTIONS GENERAL IMPORTANT INFORMATION Check the inside of the larger pieces in your box for other materials packed inside. When assembling components, place on a non-abrasive surface (i.e. shipping box) to avoid scratching. We recommend an area approximately 5’x 8’ for unobstructed assembling.
- Page 3 AG14005 ASSEMBLY INSTRUCTIONS INFORMATION GENERAL 1. Read over fence instructions first. Your gate and fence will work better together if you first take the time to read and understand your fence. 2. Pre-assemble the gate frame. Please do not screw the gate frame together until you have temporarily assembled the gate frame.
- Page 4 AG14005 ASSEMBLY INSTRUCTIONS DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS 50in. 48in. 3.94in. 58in. 56in. 36in. 36in. 2in. Ground Gate Jig (Vinyl) Metal Post Stabilizer 52in. 42in. String Line Ground WamBam WamBam Ornamental Anchor Pipe Anchor WWW.WAMBAMFENCE.COM...
- Page 5 AG14005 ASSEMBLY INSTRUCTIONS LAY OUT MATERIALS STEP 1: Aluminum Gate Hinge (2) Metal Post Gate Jig (1) Gate Post Cap (2) Stabilizer (1) 1½” x 3½” x 55” Latch Finger (1) Latch Catch (1) Bottom Rail (1) Middle Rail (1) Top Rail (1) 1”...
- Page 6 AG14005 ASSEMBLY INSTRUCTIONS INSTALL GATE JIG, POST ANCHORS, AND POSTS STEP 2: STEP 2.1 STEP 2.2 Identify the location of your gate. Dig a trench Identify the location of the Metal Post 60” long x 6” wide x 5½” deep. Stabilizer and pound it into the ground.
- Page 7 AG14005 ASSEMBLY INSTRUCTIONS STEP 2.7 Make sure to fasten the fence panels before attaching the gate. INSERT PICKETS STEP 3: STEP 3.1 STEP 3.2 Insert the Flat Top and Spear Top Insert the pickets into the Bottom Rail Pickets into the Middle Rail in the pattern and align the holes in the pickets with the illustrated.
- Page 8 AG14005 ASSEMBLY INSTRUCTIONS STEP 3.3 STEP 3.4 Align the Top Rail over Fasten (17) 5/8” Self-Drilling Stainless Steel Screws the pickets and insert the (O). Adjust the torque setting to release at the pickets accordingly. point when the head of the screw is flush with the rail.
- Page 9 AG14005 ASSEMBLY INSTRUCTIONS STEP 4.3 STEP 4.4 Insert the Bolts (M), fasten Flip the unit over, and insert the unit into the opposite gate end assembly. the nuts, and tighten. ATTACH HINGES AND LATCH FINGER STEP 5: STEP 5.1 STEP 5.2 Attach the Aluminum Gate Hinges to the Attach the Latch Finger...
- Page 10 AG14005 ASSEMBLY INSTRUCTIONS ATTACH THE GATE TO THE FENCE PANEL STEP 6: STEP 6.1 Use temporary spacers or blocks to rest the gate on during alignment and installation. Fasten the hinges using (8) total 11/4” self-drilling stainless steel screws. STEP 6.2 Swing the gate open and drive (16) total 11/4”...
- Page 11 AG14005 ASSEMBLY INSTRUCTIONS STEP 6.3 Align and fasten the Latch Catch with (4) 5/8” self-drilling stainless steel screws. Congratulations! You did it! Go grab a beverage of your choice, admire your handiwork, and show us what you got by entering our annual photo contest! WWW.WAMBAMFENCE.COM...
- Page 12 AG14005 ASSEMBLY INSTRUCTIONS INSTALL OVER A ALTERNATIVE APPLICATION: SIDEWALK OR PATH STEP 1.1 Option 1: If the sidewalk is less than 52”, use the gate jig as a temporary spacer. Proceed installing the panels according to the fence’s install guide. Sidewalk/path INSTALL OVER A ALTERNATIVE APPLICATION:...
- Page 13 AG14005 ASSEMBLY INSTRUCTIONS 6935 Reames Rd. Ste. K. Charlotte, NC 28216 hmmm@wambamfence.com 704-892-5222 877-778-5733 WWW.WAMBAMFENCE.COM WWW.WAMBAMFENCE.COM...
