- Page 1 (HORIZONTAL MULTI-STAGE) DISTRIBUTION PUMP SYSTEM OPERATION & MAINTENANCE MANUAL Manufactured With Pride In The USA www.ameriwater.com • 800-535-5585 AmeriWater • 3345 Stop 8 Rd. • Dayton, OH 45414 P/N 98-0112A...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1.0 THEORY OF OPERATION................1 2.0 INSTALLATION ................... 2 3.0 START-UP ....................3 4.0 HMS PUMP CURVE ..................4 5.0 ADJUSTING THE TIMER (DUAL PUMPS ONLY) ........5 6.0 SPARE PARTS LIST ................... 6 7.0 DRAWINGS ....................7 7.1 S... -
Page 4: Theory Of Operation
THEORY OF OPERATION The AmeriWater distribution pump takes the water from the storage tank, pumps it through the distribution loop to the points of use for dialysis, and re-circulates the water back through the piping to the storage tank. This provides pressurized water to each dialysis wall box, in addition to the re-circulation of the water. -
Page 5: Installation
5. Locate the pump control on a wall as close to the pump system as possible. When installing a distribution pump along with an AmeriWater Central Water System, refer to the Plumbing and Instrumentation Diagram (P&ID) for the best location, and where connections are made. -
Page 6: Start-Up
START-UP 1. Open the inlet and outlet valves to the pump and allow the water in the storage tank to “flood” the inlet of the distribution pump(s). If the storage tank does not have water in it, fill it to above the lowest float switch before attempting to use the pump(s). -
Page 7: Hms Pump Curve
HMS PUMP CURVE P/N 98-0112A... -
Page 8: Adjusting The Timer (Dual Pumps Only)
Adjusting the Timer (Dual Pumps only) While the power is off, and the system is properly locked out; open the control panel. Located in the middle of the panel; you will see the timer like the one shown below. To adjust the timer;... -
Page 9: Spare Parts List
Spare Parts List Part # Description 80-HMS1 Pump, 1.5 HP, Single Phase, 38GPM 80-HMS3 Pump, 1.5 HP, Three Phase, 38GPM 041-0033 Check Valve, Ball Spring Loaded 43-0021 Stainless Steel Pressure Gauge 0-100psi CBM 43530710 Stainless Steel Pressure Gauge 0-100psi 61670245 Contactor, 9 AMP, 3 Pole, 120V Coil 61760226 Motor Contactor/Overload 12 AMP Maximum... -
Page 10: Drawings
DRAWINGS Single Distribution Single Phase Controller P/N 98-0112A... - Page 11 Single Distribution Single Phase Controller Schematic P/N 98-0112A...
-
Page 12: Single Distribution 208V Three Phase Controller
Single Distribution 208V Three Phase Controller P/N 98-0112A... - Page 13 Single Distribution 208V Three Phase Controller Schematic P/N 98-0112A...
-
Page 14: Single Distribution 230V Three Phase Controller
Single Distribution 230V Three Phase Controller P/N 98-0112A... - Page 15 Single Distribution 230V Three Phase Controller Schematic P/N 98-0112A...
-
Page 16: Dual Distribution 208V, 230-460V Three Phase Controller
Dual Distribution 208V, 230-460V Three Phase Controller P/N 98-0112A... - Page 17 Dual Distribution 208 Volt Three Phase Controller Schematic P/N 98-0112A...
- Page 18 Dual Distribution 230-460V Three Phase Controller Schematic P/N 98-0112A...
-
Page 19: Dual Distribution Single Phase Controller
Dual Distribution Single Phase Controller P/N 98-0112A... - Page 20 Dual Distribution Single Phase Schematic P/N 98-0112A...
-
Page 21: Single Distribution Pump Assembly
Single Distribution Pump Assembly P/N 98-0112A... -
Page 22: Dual Distribution Pump Assembly
Dual Distribution Pump Assembly P/N 98-0112A... - Page 23 (PVC). The AmeriWater system you have purchased may contain PVC or stainless steel parts. While warnings are only required in the State of California, AmeriWater has initiated the use of Prop 65 labeling for all products to ensure compliance with California regulations. Please note that the above warning does not necessarily mean that the product that you have purchased is unsafe.
