9E428-12/36 and 9E429-12/36 Module Specific Information
MULTICASTS
Displays the number of multicasts received.
LINK STATUS
Indicates whether there is a physical connection from this port to another 10Base-
FL device. One of the following values appears:
• Link - There is a 10Base-FL link signal present; there is a valid physical
connection from this port to another 10Base-FL device.
• No Link - There is no 10Base-FL link signal present; there is no valid physical
connection from this port to another 10Base-FL device.
• N/A
PORT TYPE
Displays one of the following values:
• MMF ST
• SMF ST
PORT STATUS
Indicates whether the port has been turned on or off administratively. You will see
one of the following values:
• ENABLED - The port is turned on administratively.
• DISABLED - The port is turned off administratively.
NOTE
Enable or disable ports from the Bridge Configuration screen.
APPLICATION
Displays BRIDGING, indicating that the port is operating as a bridge with a high-
speed backbone connection.
OPERATION MODE
Displays one of the following values:
• STANDARD ENET - The port can either transmit data or receive data, but not
both at the same time. Therefore, the port is running at 10 Mbps.
• FULL DUPLEX - The port can transmit and receive data at the same time.
Therefore, the port is running at 20 Mbps.
