- Page 2 SCHÉMA ÉLECTRIQUE POUR LA MAINTENANCE DE VOTRE CHAUFFE-EAU THERMODYNAMIQUE ELECTRIC DIAGRAM SCHAKELSCHEMA VOOR DE SERVICEBEURT VAN UW THERMODYNAMISCHE WATERVERWARMER STROMLAUFPLAN FÜR DIE WARTUNG IHRES WARMWASSERBEREITERS MIT WÄRMEPUMPE SCHEMA ELETTRICO PER LA MANUTENZIONE DELLO SCALDACQUA TERMODINAMICO SCHEMAT POŁĄCZEŃ ELEKTRYCZNYCH PAŃSTWA TERMODYNAMICZNEGO PODGRZEWACZA WODY SCHEMA ELECTRIQUE SONDE AIR ELECTRIC DIAGRAM...
- Page 3 Keep the manual, even after the product has been installed. WARNINGS This product is not intended for use by persons (including children) whose physical, sensory or mental capacities are reduced, or persons without experience or knowledge, unless they have been given instructions & monitored previously when using the appliance by a person responsible for their safety.
- Page 4 WARNINGS 3/ If the appliance is to be installed in a room or location where the ambient temperature is permanently above 35°C, provide ventilation in the room. 5/ Do not use volumes V0, V1 or V2 if installing this product in a bathroom. Volume V2 can, however, be used if the dimensions cannot accommodate another size.
- Page 5 WARNINGS ELECTRICAL CONNECTION Before taking off the cover, make sure that the power is turned off to prevent injury or electric shock. The electrical installation must include an omnipolar cut-off device (circuit-breaker, fuse) upstream of the appliance, complying with local installation rules in force (30mA differential circuit breaker).
-
Page 6: Table Of Contents
Contents OVERVIEW 1. Important recommendations 2. Content of the packaging 3. Handling 4. Operating principle 5. Technical characteristics 6. Dimensions – structure 7. Glossary INSTALLATION 1. Positioning the product 2. Installation in ambient configuration (without ducting) 3. Installation in ducted configuration (2 ducts) 4. -
Page 7: Overview
Overview Installation Maintenance Warranty Product overview 1. Important recommendations 1.1. Safety instructions Installation and service work on thermodynamic water heaters can be hazardous due to high pressures and live parts. Thermodynamic water heaters must be installed, commissioned and maintained by trained and qualified personnel only. -
Page 8: Handling
Overview Installation Maintenance Warranty 3. Handling The product incorporates several handles making it easier to move to the location where it will be installed. To transport the water heater to the installation location use the lower and upper handles. Acceptable position Prohibited positions Follow the transport and handling recommendations on the water heater's packaging. -
Page 9: Technical Characteristics
Overview Installation Maintenance Warranty 5. Technical characteristics Model 200L 200L C 270L 270L C Dimensions (Height x Width x Depth) 1617 x 620 x 665 1957 x 620 x 665 Weight empty Tank capacity Hot water/cold water connection ¾ ʺ M Anti-corrosion protection ACI Hybrid Rated water pressure... -
Page 10: Dimensions/Structure
Overview Installation Maintenance Warranty 6. Dimensions/structure È MODEL COIL COIL Condensate outlet 1166 1166 1525 1525 Total height 1617 1617 1957 1957 Cold water inlet Hot water outlet 961 1300 1300 Total width Total depth 60° Inlet dimensions Exchanger inlet Dimensions in mm... -
Page 11: Glossary
Overview Installation Maintenance Warranty 7. Glossary Directional inlet 11 Terminal assembly 21 Front column Rear cover 12 Front cover 22 Lower column cap Filtered 13 Compressor 23 ACI wiring Capacitor 15μF 14 Compressor jacket 24 Regulation board Expansion valve 15 Jacket cover 25 Compressor wiring Hot gases valve assembly 16 Column rail mounting... -
Page 12: Installation
Overview Installation Maintenance Warranty Installation 1. Positioning the product You must install a retention tank under the water heater if it is positioned in an attic or above inhabited premises. Minimum height needed from floor to The identification label ceiling to install the product: located above the hot water outlet must be accessible at all times. -
Page 13: Installation In Ambient Configuration (Without Ducting)
Overview Installation Maintenance Warranty 2. Installation in a non-ducted configuration. Interior/Interior Unheated location at temperatures above 5°C and isolated from the heated rooms of the house. "Ducting" setting to be set to "Interior/Interior" Recommended location = underground or semi-underground, room where the temperature is higher than 10°C all year round. -
Page 14: Installation In Ducted Configuration (2 Ducts)
Overview Installation Maintenance Warranty 3. Installation in ducted configuration (2 ducts). Exterior/Exterior Location is at least frost-free (T > 1°C). "Ducting" setting to be set to "Exterior/Exterior" Recommended location: living space (the thermal losses of the water heater are not lost), near the outer walls. Avoid placing the water heater and/or the ducts close to bedrooms for sound comfort. -
Page 15: Installation In Semi-Ducted Configuration (1 Discharge Duct)
Overview Installation Maintenance Warranty 4. Installation in semi–ducted configuration (1 discharge duct). Unheated location at temperatures above 5°C and isolated from the Interior/Exterior heated rooms of the house. "Ducting" setting to be set to "Interior/Exterior" Recommended location = underground or semi-underground, room where the temperature is higher than 10°C all year round. -
Page 16: Prohibited Configurations
Overview Installation Maintenance Warranty 5. Prohibited configurations • Water heater drawing air from a heated room. • Connection to the CMV. • Connection to the attic. • Ducting for suction of outside air and discharge of fresh air inside. • Connection to a Canadian well. •... -
Page 17: Hydraulic Connection
Overview Installation Maintenance Warranty 6. Hydraulic connection The use of a sanitary loop is strongly discouraged: this type of installation causes a destratification of the water in the heater and results in the increased operation of the heat pump as well as the electrical resistance The cold water inlet is marked by a blue collar and the hot water outlet by a red collar. - Page 18 Overview Installation Maintenance Warranty 6.2. Hot water connection Do not connect the hot water connection directly to the copper pipes. It must be equipped with a dielectric connection (supplied with the appliance). In case of corrosion of the threads of the hot water connection not equipped with this protection, our warranty will not apply.
- Page 19 Overview Installation Maintenance Warranty Water quality The characteristics of the primary circuit water used from the time of commissioning, and for the working life of the boilers, will conform to the following values: • When filling a new installation, or when an installation has been completely emptied, the water used for filling should conform to the following values: TH <...
- Page 20 Overview Installation Maintenance Warranty 6.5. Condensate removal The circulating air cools in contact with the evaporator and causes the water contained in the air to condensate. The flow of condensed water at the back of the heat pump must be carried away from the heat pump by plastic pipes in order to drain the condensates.
-
Page 21: Air Duct Connection
Overview Installation Maintenance Warranty 7. Air duct connection When the volume of the room where your thermodynamic water heater is installed is less than 20m , it can be connected to air ducts with a diameter of 160mm. If the air ducts are not insulated, condensation may appear on them during operation. - Page 22 Overview Installation Maintenance Warranty 7.1. Lengths of permitted ducts. Standard configurations Exterior/Exterior ducting Air Outlets/Inlets Roof Wall Roof Wall Roof Wall Semi-rigid galvanised duct Ø160mm 12 m 12 m 10 m Lengths Max. HDPE duct Ø 160 mm L1 + L2 28 m 26 m 16 m...
-
Page 23: Electrical Connection
Overview Installation Maintenance Warranty 8. Electrical connection Refer to the electrical wiring diagram on the next to last page. The water heater can only be turned on after it has been filled with water. The water heater must be permanently powered by electricity. The water heater can only be connected and operated on a single-phase 230V AC grid. -
Page 24: Connection Of Optional Equipment
Overview Installation Maintenance Warranty 9. Connection of optional equipment Before any operation, make sure to turn the appliance off. Refer to the disassembly instructions on the front cover for accessing the customer's terminal block. A cable bushing is specifically provided for connections. Be sure to use it. The use of a 2x0.5mm²... - Page 25 Overview Installation Maintenance Warranty Inverter PV panels MP POWER AC connection Signal 230V~ - 50Hz 3G 25mm² 3G 15mm² 2x 075mm² 9.2. Boiler connection Power supply For appliances equipped with an internal heat exchanger that will be coupled to a boiler, the boiler must be connected to the water heater.
- Page 26 Overview Installation Maintenance Warranty 9.3. Connection to a solar station. A solar heating station can be connected to the water heater Power supply (unit with heat exchangers in "solar" mode). In this configuration, the water heater only operates when it receives a signal from the solar station.
-
Page 27: Start-Up
Overview Installation Maintenance Warranty 10. Start-up 10.1. Filling the water heater ❶ Open the hot water taps. ❷ Open the cold water tap on the safety unit (make sure that the unit drain valve is in the closed position). Close the hot water taps after filling is completed. The water heater is now full of water. ❸... - Page 28 Overview Installation Maintenance Warranty 10.3. Installation settings. Re-access the installation's different settings: Settings • Date and time Set the day and confirm. Proceed in the same way for the month, the year, the hour and the minutes. Validate or not the automatic time change •...
- Page 29 Overview Installation Maintenance Warranty • Photovoltaic/Smart-grid: This setting allows you to activate the connection of the product with a photovoltaic system. The operation results in the forced start of the heat pump when a signal from the photovoltaic system is received by the water heater.
- Page 30 Overview Installation Maintenance Warranty 10.6. Choice of operating mode Mode Pressing the key accesses the menu In AUTO mode: This operating mode automatically manages the choice of energy that ensures the best compromise between comfort and savings. The water heater analyses the consumptions from the previous days to adapt hot water production to the actual needs.
-
Page 31: Use
Overview Installation Maintenance Warranty 1. Control panel. Review the information Follow the instructions Access the settings MENU Lock the settings Navigate Decrease/Increase the values Validate Return to the previous screen 2. Description of pictograms. Electrical backup currently Recorded forced operation operating Heat pump currently operating Recorded/ongoing absence... -
Page 32: The Main Menu
Overview Installation Maintenance Warranty 3. The main menu. Navigate the MENU Access the Follow the instructions on Decrease Increase Validate settings the screen the values the values Occasionally increase the production of hot water: Set the number of days of BOOST operation (from 1 to 7). The water heater resumes its initial operation at the end of the selected time period. -
Page 33: Operating Modes
Overview Installation Maintenance Warranty 4. Operating modes. 4.1 Modes in "Thermodynamics only" installation: AUTO: The setpoint temperature is thus automatically adjusted between 50 and 62° C depending on the consumption history. The water heater preferentially selects the heat pump to operate. The electrical backup can be activated automatically in support. -
Page 34: Maintenance
Overview Installation Maintenance Warranty Servicing, Maintenance and Troubleshooting 1. Tips for the user. The water heater ishould be drained if the absence mode cannot be used or when the appliance is switched off. Proceed as follows: ❶ Cut the power supply. ❷... -
Page 35: Opening The Product For Maintenance
Overview Installation Maintenance Warranty Access to the regulator adjusting screw by non-refrigeration personnel is prohibited. Any adjustment of the regulator without approval from the manufacturer may lead to voiding of the warranty for this product. It is not recommended to touch the regulator setting until you have exhausted all other repair solutions. -
Page 36: Troubleshooting
Overview Installation Maintenance Warranty 4. Fault diagnostic. In the event of a fault, or when no heat or steam is issued from the filling point, switch off the power supply and inform your installer. Troubleshooting operations must be carried out exclusively by a professional. 4.1. - Page 37 Overview Installation Maintenance Warranty Code displayed Cause Consequence Troubleshooting Check the connections of the compressor (mark Pressure switch HP stopped. R1), the pressure switch, the start capacitor (15mF) Error 25 opening or thermal Heating in ELEC. and the hot gas valve (Mark T2). Check the compressor safety resistances of the compressor coils.
- Page 38 Overview Installation Maintenance Warranty Fault observed Possible cause Diagnostics and troubleshooting No more heat No power supply to the water Check the presence of voltage on No hot water heater: fuse, wiring ... the power cables Check the installation settings (see the operating ranges) Not enough hot water Hot water heater not large enough...
-
Page 39: Warranty
Overview Installation Maintenance Warranty Warranty 1. Scope of the warranty. This warranty does not cover failures due to: • Abnormal environmental conditions: • All types of damage caused by shaking or the appliance falling during handling after leaving the factory. •... -
Page 40: Warranty Conditions
Overview Installation Maintenance Warranty 2. Warranty conditions. The water heater must be installed by an authorised person in accordance with industry practices, the standards in force and the instructions from our technical services. It must be used normally and regularly serviced by a specialist. Under these conditions, our warranty is exercised by exchange or free supply to our Distributor or Installer of the parts deemed defective by our technicians, or if necessary of the appliance, excluding labour or transportation costs and any extended warranty. -
Page 41: Certificate Of Conformity
Overview Installation Maintenance Warranty 3. Certificate of conformity. DECLARATION OF CONFORMITY DIRECTIVE RED 2014/53/EU (*) SATE hereby declares that the equipment referenced below complies with the essential requirements of the RED 2014/53/EU Directive. The complete EU declaration of conformity concerning this equipment is also available on request from our after-sales service (see address and contact details at the end of the instructions).
