Summary of Contents for Atlantic CHAUFFEO
- Page 2 General Warnings This appliance is not designed to be used by people (including children) of reduced physical, sensory or mental capacity, or those lacking previous experience or knowledge unless they have received prior instruction or supervision from someone responsible for their safety, about the use of the appliance.
- Page 3 General Warnings • A pressure reducer (not supplied) is required when the feed pressure is greater than 5 bar - 0.5 MPa. It must be fitted to the cold water inlet, after the meter. • C onnect the safety unit to a drain pipe, kept in the open air, in an environment not subject to frost (4°C to 5°C min.), on a continuous downward gradient in order to drain the expansion water from the heater or if draining the water heater.
-
Page 4: Table Of Contents
Installation and maintenance manual Water heater Contents Installation Before beginning ..........32 Contents of the package ............32 Accessories required ............... 32 Tooling required ..............33 Labour ..................33 General installation diagram ......34 Where to install my water heater ...... 36 Precautions ................ -
Page 5: Before Beginning
Installation Manual: Installation 1. Before starting 1.1. Contents of the package Your package consists of: easyFIX for Steatite vertical wall-mounted models 50 liters unavailable 75 to100 liters 150 to 200 liters 1 of 2 brackets Package with installation Your water heater: Dielectric union Votre chauffe-eau Emballage avec... -
Page 6: Tooling Required
Installation Manual: Installation Tripod Surround kit for horizontal wall-mounted versions - For vertical wall-mounted models. Underside connection Mandatory for walls not able to hold the weight for water heaters greater than 100 L. Mandatory for mounting on the ceiling. Can be used to replace the Mounting system mountings of an older appliance. -
Page 7: General Installation Diagram
Installation Manual: Overall assembly diagram Electrical distribution board 16 A circuit breaker, day/night switch and 30 mA differential INSTALLATION PRECAUTIONS: • Temperature at the installation point should be between 4°C and 35°C • Position the water heater as close as possible to the water supply rooms •... - Page 8 Installation Manual: Overall assembly diagram General installation diagram Example with a vertical wall-mounted water heater Pressure reducer Mains water The pressure reducer is an additional accessory which should be installed at your water meter’s inlet 000 0000 outlet if the water pressure in your house is greater than 5 bar (0.5 MPa).
-
Page 9: Where To Install My Water Heater
Installation Manual: Place of installation 2. Where to install my water heater? 2.1 Precautions • Choose a place of installation whose temperature is always between 4°C and 35°C. • The water heater must be positioned as close as possible to the major draw-off points (bathroom, kitchen, etc.) • If it is positioned outside the living area (cellar, garage), the pipes and the safety units (safety unit, pressure limiter) must be insulated. • Make provision in the room for ventilation to prevent condensation and corrosion of the water heater paint. • Ensure that the supporting element (wall or ceiling) is sufficiently resistant to accommodate the weight of the water heater full of water (see table p. -
Page 10: How To Install My Water Heater
Installation Manual: Fitting the water heater 3. How to install my water heater? 3.1 Vertical wall-mounted water heater Cut the template printed on the cardboard and use it to make the markings Installation template Poids indicatif du chauffe-eau rempli Drill then plug using (Ø) 10 mm mini Capacité... -
Page 11: Vertical Water Heater On Base
Installation Manual: Fitting the water heater Specific case: Fitting a vertical wall-mounted water heater on a tripod The use of a tripod is mandatory when fitting a water tank with a capacity greater than 100 L on a non load-bearing wall (cannot support the weight of the full tank). -
Page 12: Wall-Mounted Horizontal Water Heater - Side Connection
Installation Manual: Fitting the water heater 3.4 Horizontal wall-mounted water heater- Side connection Essential: Align the pick-ups vertically with the hot water outlet (red) above the cold water (blue). CEILING WALL FLOOR Mounting procedure: figure 1 figure 2 - Assemble the belts and brackets using the nuts and bolts in the package without tightening them (figs. -
Page 13: Connecting The Water Heater To The Water Connections
Installation Manual: Water heater water connections 4. Water heater water connections The water heater must be connected in accordance with the standards and regulations in the country in which it is installed (for France: DTU Plumbing 60-1). 4.1 Conventional connection Connect the NEW safety unit to the cold water inlet (blue) on your water heater. -
Page 14: Connection With Pressure Reducer
Algemeen installatieschema Installation Manual: Water heater water connections Voorbeeld met een verticale muurboiler 4.3 Connecting to a pressure reducer A, contacts- dag/nacht eelschakelaar Ingang The pressure reducer is mandatory if the water pressure in your home is greater than 5 bar (0.5 MPa). waterleiding 000 0000 Watermeter... -
Page 15: Connecting The Water Heater To The Electricity
Installation Manual: Connecting the water heater to the electricity 5. Connecting the water heater to the electricity SWITCH OFF THE ELECTRICITY! AUTO AUTO AUTO AUTO Check the compatibility of the water heater with the electrical installation. If the water heater is pre-wired, connect the water heater’s power supply cable to a cable outlet (the water heater should not be connected to a socket). -
Page 16: Domestic Maintenance Advice
Installation Manual: Domestic maintenance advice 7. Domestic maintenance advice Your appliance should be checked by a professional every 2 years, in order to guarantee its long-term performance. 7.1 The safety unit Manœuvrez régulièrement (au moins une fois par mois), Move the safety unit valve regularly (at least once a month). la soupape du groupe de sécurité. -
Page 17: Maintaining The Tank
Installation Manual: Scope of the warranty 7.3 Maintaining the tank Check the condition of the magnesium anode every two years and replace it if its diameter is less than 10 mm (in the case of ACI versions, the anode does not require any maintenance). It is strongly recommended to have maintenance performed on the tank by a professional every 2 - 3 years depending on the quality of the water: draining and limescale removal. -
Page 18: Warranty Conditions
1641 et seq. of the civil code. In no case does the failure of a part justify the replacement of the water heater. Atlantic holds all the spare parts at your disposal for a period of 7 years. - Page 19 Installation and Maintenance manual Water heater Contents Technical Specifications Technical specifications ........47 Vertical wall-mounted water heater (VW) ......47 Vertical water heater on base (VB) ........49 Horizontal water heater (HM) connected underneath ..50 Horizontal water heater (HM) side connection ....51 Presentation of components ......
-
Page 20: Technical Specifications
Technical specifications I. Technical specifications I.1 Vertical wall-mounted water heater (VW) 50 litres 75 litres 100 litres Voltage (V) 230 V single-phase Resistance Shielded Steatite Shielded Steatite Shielded Steatite Power (W) 1,200 1,200 1,200 1,200 1,200 1,200 Ø Dimensions (mm) Real heating time** 2 h 26 min 2 h 46 min... - Page 21 Technical specifications 100 litres 150 litres 200 litres compact compact compact Voltage (V) 230 V single-phase Resistance Shielded Power (W) 1,200 1,650 2,200 Ø 1,000 1,250 Dimensions 1,050 (mm) Real heating time** 5 h 32 min 5 h 38 min 5 h 33 min 1.024 1.37...
-
Page 22: Vertical Water Heater On Base (Vb)
Technical specifications I.2 Vertical water heater on base (VB) 150 l 200 litres 250 litres 300 litres Voltage (V) 230 V single-phase Resistance Shielded Shielded Steatite Shielded Steatite Shielded Steatite Power (W) 1,650 2,200 2,200 3,000 3,000 3,000 3,000 Ø 1,170 1,485 1,485... -
Page 23: Horizontal Water Heater (Hm) Connected Underneath
Technical specifications I.3 Horizontal water heater (HW) with underside connection 75 litres 100 litres 150 litres 200 litres Voltage (V) 230 V single-phase Resistance Shielded Power (W) 1,200 1,200 1,650 2,200 Ø 1,140 1,460 Dimensions (mm) Real heating time** 4 h 07 min 4 h 57 min 4 h 53 min 5 h 24 min... -
Page 24: Horizontal Water Heater (Hm) Side Connection
Technical specifications I.4 Horizontal water heater (HW) side connection 75 litres 100 litres 150 litres 200 litres Voltage (V) 230 V single-phase Resistance Shielded Power (W) 2,000 2,000 2,000 2,000 Ø 1,000 1,255 Dimensions (mm) Variable Real heating time** 2 h 36 min 3 h 27 min 4 h 41 min 6 h 28 min... -
Page 25: Presentation Of Components
Your water heater: Wiring diagrams II. Presentation of the components II.1 Components making up the shielded vertical wall-mounted models Cold water Hot water outlet inlet Power supply cable Thermal safety mechanism Thermostat II.2 Components making up Steatite vertical wall-mounted models Thermostat Thermal safety mechanism... -
Page 26: Steatite Stable Models
Your water heater: Wiring diagrams II.4 Steatite stable model components Thermostat Thermal safety mechanism Heater element Power supply cable 200 L 250 and 300 L II.5 Shielded horizontal model components Thermostat Thermal safety mechanism Power supply cable III. Specific installation procedures Potentiometer Adjusting the temperature The factory temperature setting is 65°... -
Page 27: Troubleshooting Guide
Your water heater: Troubleshooting guide V. Troubleshooting guide V.1 No hot water Action to take Solution Cause 1. Have the electrical power supply If there is no current Electrical power supply fault. checked by a professional (using a at the water heater’s terminals: multimeter). -
Page 28: Electric Meter Which Breaks The Circuit
Your water heater: Troubleshooting guide Action to take Solution Cause 1. Cut-off the water heater power Null or infinite value. Replace the faulty resistor. (the circuit breaker should be in the OFF position). Value in ohms > 0. Replace the thermostat. AUTO AUTO 2. -
Page 29: Leak Problem
Your water heater: Troubleshooting guide V.4 Leak problem Action to take Solution Cause Leak located on the hot and cold water take-offs 1. Switch off the electrical power supply Reconnect all the connections (see Poor connector sealing 2. Drain the water heater (see p. 43). p.
