NetWay1D Chassis Mechanical Drawing and Dimensions

Fig. 2
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IINetWay1D
- 4 -
(H x W x D approx.):
1.7" x 4.1" x 7.2" (44mm x 105mm x 183mm)
4.1" (105mm)
Aux.
OUT IN + ---
PoE
ON
H19U
7.2"
(183mm)
1.7"
(44mm)
NetWay1D Installation Guide
MEMBER
