ZCV3622N, ZCV3622NE, ZCV3622NE2, ZCV3622LP, ZCV3622LPE, ZCV3622LPE2,
Model Numbers:
ZCVRB3622N, ZCVRB3622NE, ZCVRB3622NE2, ZCVRB3622LP, ZCVRB3622LPE,
ZCVRB3622LPE2
ANSI Z21.88-2017 • CSA 2.33-2017 Vented Gas Fireplace Heaters,
Certified to:
Installation Instructions
CSA 2.17-2017
ZCV3622 SOLARA
ZCVRB3622 SKYLINE
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
A Division of R-Co. Inc.
2340 Logan Ave.
Winnipeg, Manitoba Canada
R2R 2V3 Ph.: (204) 632-1962
Printed in Canada November 20, 2019
Part# 36ZCV-MAN17
Advertisement
Table of Contents
Related Manuals for Kingsman marquis SOLARA ZCV3622NE2
Summary of Contents for Kingsman marquis SOLARA ZCV3622NE2
-
Page 1: Cover
Installation Instructions ZCV3622N, ZCV3622NE, ZCV3622NE2, ZCV3622LP, ZCV3622LPE, ZCV3622LPE2, Model Numbers: ZCVRB3622N, ZCVRB3622NE, ZCVRB3622NE2, ZCVRB3622LP, ZCVRB3622LPE, ZCVRB3622LPE2 ANSI Z21.88-2017 • CSA 2.33-2017 Vented Gas Fireplace Heaters, CSA 2.17-2017 Certified to: ZCV3622 SOLARA ZCVRB3622 SKYLINE This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. -
Page 2: Table Of Contents
Table of Contents Cover..................................Table of Contents..............................Pre-installation Questions and Answers / Operations and Maintenance Instructions..........Safety Screen Installation............................Warnings, Installations and Operations - Installation Regulations................Installation Requirements for the Commonwealth of Massachusetts / Carbon Monoxide (CO) Detector....Mobile Home/Manufactured Housing Installation....................Installation &... - Page 3 Proflame 2 Proflame 2 Parts List / Basic System / Configuration GTMFL................Proflame 2 Module and Remote Control......................... Cold Climates – CPI Setting - Proflame 2 Remote Control..................Proflame 2 Remote Control............................ 57-58 Proflame 2 Label Diagram..............................Venting Vent Terminal Clearances............................General Vent Installation / Installation Of Side Wall Venting..................
-
Page 4: Pre-Installation Questions And Answers / Operations And Maintenance Instructions
Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used. -
Page 5: Safety Screen Installation
ZCV3622 / ZCV362RB Safety Screen Installation / Removal Included with fireplace: [1] Safety Screen NOTE: Screen is symmetrical from top to bottom. ⚠ WARNING: Wait until unit is COMPLETELY cool before touching glass or attempting to install or remove Child Safety Screens. SIDE VIEW TOP VIEW Upper Clip... -
Page 6: Warnings, Installations And Operations - Installation Regulations
Warnings, Installations and Operations - Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or with the National Electrical Code;... -
Page 7: Installation Requirements For The Commonwealth Of Massachusetts / Carbon Monoxide (Co) Detector
Installation Requirements for the Commonwealth of Massachusetts In the Commonwealth of Massachusetts, the installer or service agent shall be a plumber or gas fitter licensed by the Commonwealth. When installed in the Commonwealth of Massachusetts or where applicable codes; the unit shall be installed with a CO detector per the requirements listed below. -
Page 8: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 9: Recommendations For Finishing Of Clean View Linear Products
Recommendations for Finishing of Clean View Linear Products When finishing the wall around the fireplace, it is critical that the wall covering be fastened properly. It is acceptable to pre-drill holes and use self-tapping screws which may be used to fasten a backer for tile, marble, etc. Screws being installed through non-combustible board should be self-tapping type with a maximum length of 2 inches. -
Page 10: Fireplace Installations In Covered Outdoor Locations
Intertek safety certification will not apply to this installation method. This installation method must be deemed acceptable by the Authority Having Jurisdiction (AHJ) prior to the indoor gas fireplace being installed. Kingsman and Marquis Direct Vent fireplaces may be installed into outdoor locations provided they are suitably protected from direct water impingement. -
Page 11: Framing For Your Gas Fireplace
ZCV3622 / ZCVRB3622 Framing Your Gas Fireplace This section is intended for qualified installers only. Before beginning, make note of where the gas and electrical accesses are located on the unit. This will streamline the construction process. Furthermore, familiarize yourself with the venting and clearance requirements (see Venting section) for this appliance. -
Page 12: Zcv3622 / Zcvrb3622 Nailing Tab Guide
ZCV3622 / ZCVRB3622 Nailing Tab Guide 2 Nailing Tabs are located on each side of the fireplace front frame. ZCV3622 ZCVRB3622 These Nailing Tabs can be used in two ways: 1/2” Drywall Flush with Face of Fireplace –Fireplace and -Fireplace to be Framing Flush with Face of Fireplace Combustible Wall to be covered with a surround and / or Non- covered with Non-Combustibles (e.g. -
Page 13: Locating Your Appliance / Unit Dimensions
ZCV3622 / ZCVRB3622 - Locating your Appliance Installing with Top Vent A - Flat on a wall D - As a room divider B - Across the corner E - Flat on wall corner C - As an island F - Exterior wall Island installation with a top vent is possible as long as the horizontal portion of the vent system does not exceed 20 feet (6.1 m). -
Page 14: Zcv3622 / Zcvrb3622 Framing Dimensions And Clearances -With Factory Installed Flue Restrictor
ZCV3622 / ZCVRB3622 Framing Dimensions and Clearances -With Factory Installed Flue Restrictor- NOTE: Units above the following Serial Numbers will have the Flue Restrictor: ZCV3622 #2016 / ZCVRB3622- #10674 Determine whether face of fireplace will be: Flush with finished wall (e.g., for surround, cultured stone or other non combustible covering). ... -
Page 15: Zcv3622 / Zcvrb3622 Framing Dimensions And Clearances -With Factory Installed Flue Restrictor Removed
LOW ENCLOSURE ZCV3622 / ZCVRB3622 Framing Dimensions and Clearances -With Factory Installed Flue Restrictor Removed- RESTRICTOR MUST BE REMOVED BEFORE INSTALLATION NOTE: Units above the following Serial Numbers will have the Flue Restrictor: ZCV3622 #2016 / ZCVRB3622- #10674 Determine whether face of fireplace will be: ... -
Page 16: Zcv3622 / Zcvrb3622 Facing Requirements
ZCV3622 / ZCVRB3622 Facing Requirements Required Non-Combustible Areas- If you are covering the face of the fireplace: Combustibles (i.e. Drywall) may be installed up to edge of fireplace only. NOTE: MATERIALS COVERING THE FACE OF THE FIREPLACE MUST BE NON-COMBUSTIBLE It is also recommended (but optional) to attach Non-combustible facing to framing. -
Page 17: Zcv3622 / Zcv3622Rb Mantel & Mantel Leg Clearances
ZCV3622 / ZCV3622RB Mantel Clearances Before installing any mantels it is important to determine the combustibility of its material(s). There are two types of mantels to consider: Combustible and Non-Combustible. A Combustible Mantel is one that consists of material(s) that may discolor, combust, or lose its integrity in the presence of heat. -
Page 18: Zcv36S1Bl- Zcv3622 Surround Installation
ZCV36S1BL ZCV3622 Surround Installation Parts List: [1] Surround, [2] #6 DT Black Screws Step 2: Slide surround over fireplace frame. Step 3: Install DT screws through surround into top corners. Install screws into bottom corners through surround. Step 1: Remove [2] top screws in Lower Panel and open. -
Page 19: Zcvrb36S Surround Installation
ZCVRB36S Surround Installation Each kit contains: Surround Size: Side Fillers (36”W x 22-7/8”) (Qty-1) Surround Frame (Left and Right) (Qty-2) Surround Side Fillers ZCVRB36SBL (Qty-6) #6 Self Tapping Screws ZCVRB36SSS Surround Frame NOTE: See Framing Flush With Face of Fireplace on Nailing Tab Guide Page. -
Page 20: Zcv36Lmk Magnet Kit Zcv3622 / Zcvrb3622
ZCV36LMK Magnet Kit ZCV3622 / ZCVRB3622 Parts List: [2] Access Panel Brackets [2] Magnets [4] DT Screws Right Access Panel Bracket Left Access Panel Bracket Magnet Magnet [4] DT Screws Step 1: Step 2: Remove [2] top Attach left and right screws in Lower Access Panel Panel and open. -
Page 21: Fan Kit Installation
ZCV3622 / ZCVRB3622 Z36FK Fan Kit Installation ⚠ WARNING Z36FK Parts List: [1] Fan c/w 4 ft. cord & 2-14” leads Electrical Grounding Instructions [1] Wall Mount Variable speed This appliance is equipped with a three prong (grounding) plug for your protection against control shock hazard and should be plugged directly into a properly grounded three-prong [1] Thermodisc... -
Page 22: Fan Speed Control Outside Of Fireplace
Fan Speed Control Outside of Fireplace If you plan to locate the variable speed control switch for the fan outside of the fireplace and you require a constant source of AC power inside the unit for another accessory such as lights or an IPI valve system, follow one of the procedures below. -
Page 23: Zcv3622 / Zcvrb3622 Ml / Prl Liner Installation Guide
ZCV3622 / ZCVRB3622 ML / PRL Liner Installation Guide Make note of the position of the air adjustment plate before removing it. This position will have to be recalled when the air adjustment plate is reinstalled. Remove three [3] mounting screws from air adjustment plate and extract it from the firebox. (NOTE: The false bottom will have to be removed on model ZCVRB3622.) Remove the [1] Liner Retaining Screw from each side of the firebox. -
Page 24: Door And Glass Information
ZCV3322 / ZCVRB3622 Door and Glass Information Glass Cleaning Spring Replacement- ZCV3622, ZCVRB3622 It will be necessary to clean the glass periodically. *Over time, spring may need to be replaced if tension is During start- up, condensation, which is normal, forms lost. -
Page 25: Logc51 5 Piece Oak Log Set For Zcv3622
LOGC51 5 Piece Oak Log Set for ZCV3622 Glowing Embers & Vermiculite (Base Unit) Lava Rock (Base Unit) LOG 1 LOG 5 LOG 2 LOG 3 LOG 4 Pile Lava Rock around sides of Burner Tube. LOG 1 LOG 3 LOG 2 LOG 5 Log 5 will rest on Lava Rock. - Page 26 Optional: Log 4 in raised position. LOG 4...
-
Page 27: Mqlogc22 For Mqzdv3318 / 3622 / Zcv3622
MQLOGC22 for MQZDV3318 / 3622 / ZCV3622 WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. NOTE: Log 1 is a two piece assembly. Log 1 assembled and ready for install. - Page 28 MQLOGC22 for MQZDV3318 / 3622 / ZCV3622 STEP 3: Align the hole on the bottom of log #3 with the log STEP 4: Place Log #4 into place as shown. Do Not place #3 placement tab and the rest log #3 on log #2 as shown. directly over top of the multiple porting area on the left side.
-
Page 29: Mqlogc23 4 Piece Driftwood Log Set For Zcv3622
MQLOGC23 4 Piece Driftwood Log Set for ZCV3622 Glowing Embers & Vermiculite (Base Unit) Lava Rock (Base Unit) LOG 1 LOG 2 LOG 4 LOG 3 LOG 1 LOG 2 LOG 3 LOG 4 Pile Lava Rock around sides of Burner Tube. Sprinkle Vermiculite onto Lava Rock. Place Glowing Embers on sides and front of Burner Tube. -
Page 30: Mqrsp5 For Mqzdv3318/3622/Zcv3622
MQRSP5 for MQZDV3318/3622/ZCV3622 Step 1: Remove the grate bar by removing the 2 Screws MQRSP5 Parts List located on the left and right side of the grate bar as illustrated. Remove the 2 ember plates once the grate bar is removed. The 1 each MQRSP5 Rock Platform 2 screws removed must be re-installed once the grate bar is 1 each Lava Rock... - Page 31 MQRSP5 for MQZDV3318/3622/ZCV3622 Step 6: Place rocks #6 into place as shown. Do not place Step 7: Place rocks #4 into position as shown. Place the highlighted rocks into position being sure that they are crossing directly over the multiple porting areas. over the single line porting.
-
Page 32: Ulk2 Universal Light Kit (Optional Accent Lighting Kit)
ULK2 Universal Light Kit ( Optional Accent Lighting Kit) ZCV3622, ZCVRB3622 Please follow the current ANSI/NFPA 70 National Electrical Code in the USA and CAN/CSA C22.1 Canadian National Electrical Code in Canada. Contents of Kit: [2] 12V Halogen Lamps ... - Page 33 ZCVRB3622 ZCV3622 STEP 3: Place Lamps in position in firebox. Attach to fireplace with a single screw at the locations shown above for each unit. Lamps can be placed facing upward or sideways. Replace burner tube and false bottom, along with pilot shield.
-
Page 34: Accessories For Skyline, Zcvrb3622, & Zrb46 Ribbon Burner Units
Accessories for Skyline, ZCVRB3622, & ZRB46 Ribbon Burner Units ACCESSORY ITEM MQRB3632 MQRB4236 ZCVRB3622 White Glass MQG5W Yes / 5LB MAX 5LB Bag c/w Unit MQ Dealer Only Bronze Glass Yes / 5LB MAX Yes / 5LB MAX 5LB Bag c/w MQG5C Unit Cobalt Blue Glass... - Page 35 ⚠ NOTE: Glass Media must be evenly spread over the Burner and False Bottom as described on last page before Rock / Stones / and Log Accessories are placed. MQROCK2, MQROCK3, MQRBD1 - Place rocks randomly onto False Bottom. Be careful not to cover any part of the Burner Tube as sooting may occur.
-
Page 36: Gas Line Installation
1/2 PSIG (3.5 KPa). NOTE: The gas line connection may be made of 1/2” rigid pipe or an Approved Kingsman Flex Connector, such as FP15GC. -
Page 37: Millivolt System, Lighting, And Burner Control
Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING Immediately call your gas supplier from a neighbour’s phone. Follow the This appliance has a pilot which must be lighted by hand. -
Page 38: Annual Inspection List For Determining Safe Operation Of A Direct Vent Gas Fireplace
Annual Inspection List for Determining Safe Operation of a Direct Vent Gas Fireplace Refer to this checklist for proper maintenance, safe use, and operation. See each section for more specific information. 1. Inspect and operate all pressure relief mechanisms (i.e., relief dampers, spring loaded door latches) installed on your appliance to verify relief mechanisms are free from obstruction to operate. -
Page 39: Burner System Maintenance
Burner System Maintenance It is recommended to annually inspect and clean the Burner System to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. ⚠ -CAUTION- Before servicing the burner system ensure that the gas supply is turned OFF and disconnect all electrical connections to the appliance. -
Page 40: Conversion Kit Instructions - Part A
Conversion Kit Instructions – PART A Burner Orifice Kit Number Description Pilot Orifice Brass Nipple Air Shutter Hi/Lo Regulator Brass (1000-255) LP Conversion 1001-P167SI 1001-P202SI 3622-CKLP 1000-P201VE 3/8” #30 (977.167) -Millivolt- (0.907.202) NG Conversion 1001-P165SI 1001-P201SI 3622-CKNG 1000-P201VE 3/16” #51 (977.165) -Millivolt- (0.907.201) LP Conversion... - Page 41 Conversion Kit Instructions – PART A ⚠ Caution : The gas supply shall be shut off prior to disconnecting the electrical power, before proceeding with the conversion. IMPORTANT: Always check for gas leaks with a soap and water solution. DO NOT USE OPEN FLAME FOR LEAK TESTING. ⚠...
-
Page 42: Gas Conversion For Top Convertible Pilot - Part B (Series 0190Xyz)
Gas Conversion for Top Convertible Pilot – Part B (series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to LPG and from LPG to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. -
Page 43: Gas Conversion For Modulator - Part C
Gas Conversion for Modulator – PART C... -
Page 44: Zcvrb3622 Burner System Removal
ZCVRB3622 Burner System Removal Burner Burner Retainer Retainer Plumbing Access Remove four [4] screws holding down the false bottom. Remove the four [4] screws holding down the burner tube assembly. Slide the burner tube towards the left to remove from orifice. Remove main orifice using a 1/2”... -
Page 45: Component Locations
COMPONENT LOCATIONS (See Each Section For Connections & Wiring) NOTE: The gas line connection may be made of Power 1/2” rigid pipe or an Vent Approved Kingsman Flex Control Connector, such as Junction FP15GC. Since some Module municipalities have additional local codes, it is... -
Page 46: Proflame 1 Overview / Components
IPI Electronic Ignition System Overview CPI / IPI The IPI system is an advanced burner controller that Switch provides you with the option of having either a Standing- Cover Pilot, or an intermittent igniting system. This alternating mode is controlled by the CPI/IPI Switch (Continuous Pilot Ignition/Intermittent Pilot Ignition) located on the IPI System Box. -
Page 47: Remote Control Operation
-Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room Thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room thermostat. -
Page 48: Proflame 1 Parts List - Standard System
IPI Electronic Ignition Parts List – Standard System ITEM NO. PART NO. DESCRIPTION 1006-P002si Valve IPI Hi/Lo NG 1006-P003si Valve IPI Hi/Lo LP *1002-P047si Pilot Assembly-LP -24” Wire *1002-P033si Pilot Assembly-NG -24” Wire 1002-P017si Spark Electrode (with wire) *1002-P119si Spark Electrode (with wire- 35” Length) 1002-P903si Electrode Flame Sensor *1002-P910si... -
Page 49: Configuration #1: Basic Manual Hi/Lo And Manual On/Off Capabilities
Configuration #1: Basic manual HI/LO and manual ON/OFF capabilities. -
Page 50: Configuration #2: Remote On/Off And Manual Hi/Lo Capabilities
Receiver Module .584.523/521/221 1001-P221SI Receiver Module .584.523/521/221 1001-P221SI... -
Page 51: Operating The Receiver Without Batteries- Millivolt And Proflame 1
Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries. -
Page 52: Configuration #3: Remote On/Off, Variable Hi/Lo, And Fan Capabilities
Configuration #3: Remote ON/OFF, variable HI/LO, and fan capabilities. Refer to the fan installation/removal section for fan installation. -
Page 53: Electronic Ignition Lighting Instructions
Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. FOR YOUR SAFETY READ BEFORE LIGHTING: A. -
Page 54: Proflame 2 Parts List / Basic System / Configuration Gtmfl
Proflame 2 –NE2 / LPE2 -IPI System Parts List- IPI PROFLAME 2 - COMPONENT PARTS IPI - PF1 and PF2 Common Components PART NO. DESCRIPTION PART NO. DESCRIPTION 1005-P001SI Valve IPI Proflame PF2 885.001 NG - Stepper 12. 1002-P033SI TC - Pilot Burner IPI (Assembled) NG 199.033 1005-P002SI Valve IPI Proflame PF2 885.002 LP - Stepper 13. -
Page 55: Proflame 2 Module And Remote Control
Proflame 2 IFC Module and Remote Control LCD Display ON / OFF Key Thermostat Key Batteries UP / DOWN Arrow Key Mode Key IFC Module Button Within 10 seconds press the button again until Pairing Remote Control: you hear it beep. ... -
Page 56: Cold Climates - Cpi Setting - Proflame 2 Remote Control
Cold Climates – CPI Setting - Proflame 2 Remote Control Use the CPI setting during cold weather, otherwise the fireplace may have a hard time starting up and establishing a flame. The CPI (Continuous Pilot Ignition) setting will keep the firebox and fireplace exhaust vent warm during cold weather. When the firebox and exhaust vent are warm, exhaust gasses will readily flow out of the firebox. -
Page 57: Proflame 2 Remote Control
Proflame 2 Remote Control... - Page 58 Note: When Smart Thermostat is activated, manual flame height adjustment is disabled. Note: This function is only available in Room Thermostat or Smart Thermostat Control Mode.
-
Page 60: Vent Terminal Clearances
Vent Terminal Clearances Clearances are to the edge of the terminal plate. Add 6-3/4” to clearances to arrive at centerline. Local codes or regulations may require different clearances. WARNING: A HORIZONTAL VENT CERTIFIED GUARD (SAFETY CAGE) IS AVAILABLE WHEN REQUIRED BY LOCAL CODES. Canadian installations US installations Clearance above grade, veranda,... -
Page 61: General Vent Installation / Installation Of Side Wall Venting
General Vent Installation Information This gas appliance is approved to be vented either through the side wall or vertically through the roof. Only Kingsman Flex (Z-Flex) Venting Kits and components specifically approved and LABELED for this stove may be used. This appliance is also approved for use with Montigo terminations, Duravent (Direct Vent Pro) systems, Ameri-Vent Direct Vent Pipe systems, ICC Excel Direct systems, Metal Fab Sure-Seal DV systems, and Selkirk Direct Temp systems. -
Page 62: Venting Routes And Components / Horizontal Venting Table From Bottom Of Fireplace
ZCV3622 / ZCVRB3622 Venting Routes And Components Venting Routes and Components Since it is very important that the vent system maintain its How to Use the Horizontal Vent Table balance between the combustion air intake and the flue gas 1. Determine the height of the system and the number of exhaust, certain limitations as to vent configurations apply and bends required. -
Page 63: Venting Straight Up Through Roof
ZCV3622 / ZCVRB3622 Venting Straight Up Through Roof An Attic Insulation Shield must be installed where the vent passes from a lower living space into an attic space where the chimney is not enclosed. It is designed to keep insulation materials away from the chimney. When installing the Attic Insulation Shield where the chimney passes from a living space to an attic space, install the shield from below and nail in place using 1"... - Page 64 -Restrictor- Remove for Runs Under 15 Feet Clearances in horizontal venting. FDVVT40 Clearance to perpendicular wall 24 inches (60 cm). (Recommended to prevent re- circulation of exhaust products. For additional requirements check local codes.) 24” 18” MIN Clearance above highest point of exit on roof 18 inches (45cm) 43ft...
-
Page 65: Vertical Venting Over 15 Feet
Vertical Venting over 15 Feet The Air Intake plate must be adjusted down to the lowest position when venting over 15 ft. vertical. 15ʼ OR OVER VERTICAL VENTING AIR INTAKE ADJUSTMENT PLATE NOTE: Unit comes preset for short horizontal or vertical venting under a 15 feet run. Follow these instructions when venting exceeds 15 foot run. -
Page 66: Z47St24 / Z47St36 Horizontal Snorkel Terminations
Z47ST24 / Z47ST36 Horizontal Snorkel Terminations Two snorkel terminations are available if a vertical rise is necessary on the exterior side of a building: Z47ST24 (24” Tall, 14-1/2” Center to Center) Z47ST36 (36” Tall, 26-1/2” Center to Center) Follow standard horizontal venting installation procedures. If the Snorkel Termination is to be located below grade, a window well is recommended with adequate and proper drainage as per local codes. -
Page 67: Fireplace Installations Using Co Linear Flex Kits
Fireplace Installations Using Co Linear Flex Kits CAUTION – The following installation procedure is not covered under the appliance safety standard (ANSI Z21.88 – CSA 2.22 or ANSI Z21.50 – CSA 2.33) used in the safety certification of this appliance. The Intertek safety certification does not apply to this installation. -
Page 68: Glass Safety / Termination Cap Safety
-Glass Safety- All Units IT IS THE RESPONSIBILITY OF THE HOME OWNER TO ENSURE THAT NO ONE TOUCHES A HOT APPLIANCE. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance. Any safety screen, guard, or barrier removed for servicing the appliance, must be replaced prior to operating the appliance. -
Page 69: Approved For Power Vent Pvh58
Approved for Power Vent PVH58 - This appliance is approved for use with the Kingsman PVH58 Horizontal Power Vent - The PVH58 Horizontal Power Vent Termination is intended for use where standard venting configurations are not possible. NOTE: MODELS EQUIPPPED WITH MILLIVOLT/ STANDING PILOT IGNITION: Downward vertical vent runs are NOT permitted. -
Page 70: Parts Lists Pvh58 Parts List
PVH58 POWER VENT PARTS LIST NUMBER DESCRIPTION PVH58 Horizontal Power Vent Termination Power Vent Control Module – Millivolt Box PVC58MV Power Vent Control Module – IPI Box PVC58IPI Main Wiring Harness Assembly – Extension Harness (20ft) PVH20H 4/7 VENTING AND VENTING ADAPTERS For fireplaces to be converted to hard pipe (Duravent-DirectVent Pro, etc.) at the fireplace: Duravent Fireplace Adapter (ZRB46 Only) ZDVDKA... -
Page 71: Zcv3622 Parts List
ZCV3622 Parts List FIREPLACE PART NUMBERS ZCV3622ML Metal Liner Traditional Door Glass ZCV3622N (Millivolt) Fireplace Heater Rated, NG, 18,000BTU, Tempered Glass, Safety 36HB-311 Tempered Glass - ZCV3622 Screen 36HB-123A Door Latch Assembly ZCV3622NE (IPI) Fireplace Heater Rated, NG, 21,000BTU, Tempered Glass, Safety 36HB-123 Upper Door Spring Screen... -
Page 72: Zcvrb3622 Parts List
ZCVRB3622 Parts List FIREPLACE PART NUMBERS 3622RB-135 Access Panel (Requires ZCV36LMK) Child Safety Screens ZCVRB3622N (Millivolt) Linear Fireplace, Heater Rated, NG, 17,500BTU, Low-E Tempered Glass, Z36CSS ZCVRB3622 Safety Screen Replacement Safety Screen, 5lb Decorative Bronze Glass Fan Kit/ Blower ZCVRB3622NE (IPI) Linear Fireplace, Heater Rated, NG, 17,500BTU, Low-E Tempered Glass, Safety Z36FK... -
Page 73: Zcv3622 / Zcvrb3622 Common Parts And Venting
ZCV3622 / ZCVRB3622 Common Parts and Venting Catalog 1000-085 Control Variable Speed KBWC-13BV Number Description Valve System Parts - New Top convertible SIT (Millivolt) Kingsman Fireplace Venting FP15GC Stainless Steel Gas Connector Number Description 1000-P136WR Generator/Thermopile ZDVHSK Horizontal Vent Starter Kit - 3 FT Length 1001-P069SI Electrode Sparker 915.069 TC SIT... -
Page 74: Troubleshooting The Gas Control System
Troubleshooting the Gas Control System ⚠ WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. NOTE: Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is... -
Page 75: Limited Lifetime Warranty
During the first year after installation, we will provide a replacement for any component part of your unit found to be defective in materials or workmanship, including labour costs. Repair work requires prior approval by Kingsman, labour costs are based on a predetermined rate schedule and any repair work must be done through an authorized Kingsman dealer.
