S2 Video Encoder
H.265/H.264-HD/4K
（2021-8 version）
Before using this product, it is recommended that you read the guide carefully. To
ensure your personal safety and avoid physical or electrical damage to the device, please
strictly follow the instructions of this guide to install and use it under the guidance of
professionals. Incorrect electrical connections or physical installation may cause
permanent damage to the device and even threaten personal safety.
Leading solution provider of IP-based video transmission
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kiloview S2

Summary of Contents for Kiloview S2

  • Page 1 Leading solution provider of IP-based video transmission Quick Start Guide S2 Video Encoder H.265/H.264-HD/4K （2021-8 version） Before using this product, it is recommended that you read the guide carefully. To ensure your personal safety and avoid physical or electrical damage to the device, please strictly follow the instructions of this guide to install and use it under the guidance of professionals.

  • Page 2: Packing List

    1 Packing List (1) S2×1 (2) Power Supply×1 (3) Warranty card×1 (4) Quick start guide×1 2. Device Interface (1) Power Switch (6) USB Port (2) Power Port (7) 1 GbE port with PoE (3) 3.5mm Line in/Line out (8) Tally...

  • Page 3: Device Indicators

    (10) Reset（bottom） 3. Device Indicators Video status under encoding mode Green light Tally always on Red light always on Name Color Status Description Always on Power connected Power White Power off or failure Flashing Network connected LINK White Network disconnected/abnormal LED Indicators Flashing Working normally...

  • Page 4: Device Discovery

    Please make sure the camera is connected to the HDMI IN connector. ⚫ If you wish, you can connect S2 to your monitor for real time preview by HDMI OUT . ⚫ 5.Device discovery 5.1 Install Kiloview Multiview NDI Player for free...
  • Page 5 ①Click in the upper right corner to log into webpage. ②Find the device and IP address in the device list. Enter management interface through web browser.
  • Page 6 NDI for discovery and monitoring NDI video. Right click on the Studio Monitor interface，find the name of S2 in the pop up menu, click it for playing NDI video. At the same time, a gear icon will appear in the lower right corner, click it and then a browser window will pop up for logging in and accessing the Web UI of S2.
  • Page 7 6. Login to the device management page Open the Web page of S2，Default username/password is admin/admin. Note: To insure your information security, it is recommended to revise your password after you log into for the first time. 7. Work with your device 7.1 Video input checking...
  • Page 8 7.2 Streaming service Click“+”on the right side of the stream service at the bottom of S2 Web UI. Add a stream service, take RTSP protocol as an example. Select RTSP, fill in the name, service port and session ID, the other setting parameters can remain default configuration, click “OK”.
  • Page 9 Click media on the VLC - open network streaming - enter the URL address of RTSP over internet, click play at the lower right corner to start streaming. For more support while using with S2 encoders, please visit Kiloview website: https://www.kiloview.com/en/support/...

  • Page 10: Firmware Upgrading

    Kiloview will continue to provide the firmware of updating functions and fixing bug for S2. Kindly visit “ https://www.kiloview.com/en/support/download/” Select “video encoders” in the filter list > “S2”, find the latest firmware to download in the program tag. 8.2 Upgrade device firmware Login the management web page of S2, click "Settings"-- "System Settings"--"Firmware Upgrade"...

  • Page 11: Restore Factory Settings

    Note ⚫ Please not power off during the upgrade process, otherwise the device couldn’t work. ⚫ Generally speaking, it will cost 3-5 minutes to upgrade the device, if it’s still not completed after 5 minutes, please try refreshing webpage, if you still can’t access it normally, try contacting technical support.
  • Page 12 10 Note To prolong the device life，please unplug the power and keep it properly if you do not use it for a long time. Website for Official online document of S2 https://www.kiloview.com/en/support/docs/S2 Website for Kiloview official technical support https://www.kiloview.com/en/support/...
