- Page 1 DC220/230 Multifunctional HD Video Decoder USER MANUAL Changsha KILOVIEW Electronics CO.,LTD.
- Page 2 Legal Notices Subject to the receiving of this document from Changsha Kiloview Electronics Co., Ltd.,(Hereinafter referred to “Kiloview”), the following terms are understood and agreed. Or else, please stop using this document. This document is copyright of Kiloview, all rights reserved. The document covers the proprietary information of the company.
-
Page 3: Table Of Contents
CONTENTS 1 PRODUCT INTRODUCTION..............................1 1.1 A ..................................1 DVANTAGES ..................................2 1.2 P ARAMETERS 2 OPERATION GUIDANCE...............................4 3 PACKING LIST AND INTERFACE DESCRIPTION......................5 ..................................5 3.1 P ACKING LIST 3.2 I ............................... 5 NTERFACE DESCRIPTION ..................................6 3.3 L ED INDICATORS 4 INSTALLATION AND CONNECTION.......................... -
Page 4: Product Introduction
10% packet loss, excellent image output can be obtained. Decoding latency can be less than 200 ms under a typical network environment with Kiloview intelligent latency control technology. Decoding Output of H.264 Coded Video and AAC-LC/G.711 Coded Audio Supporting Bit Rate up to 40Mbps. -
Page 5: Parameters
Video decoding H.264 Audio decoding AAC/ G.711 Decoding delay ≤200ms Decoding ability Single channel video decoding Management Web operation Power supply DC 12V, 1A/ 5W /Consumption Size/ Weight 138*105*27mm/380g Operation -20℃~60℃ temperature Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 6 AAC/ G.711 Decoding delay ≤200ms Decoding ability Up to 4 channels 1080p30/ 2 channels 1080p60 Management Web operation Power supply DC 12V, 1A/ 5W /Consumption Size/ Weight 138*105*27mm/380g Operation -20℃~60℃ temperature Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 7: Operation Guidance
HDMI/SDI/VGA interface. Then drag the added video source to the output window and the decoder will start decoding it. If the decoding is normal, the video will be output. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 8: Packing List And Interface Description
Optional Parts DVI to VGA adaptor Quick start guide Certificate/Warranty card 3.2 Interface description 1、USB interface 2、SDI output 3、Reset 4、Audio output 5、Audio input 6、LED Status 7、Power input 8、100/1000M Ethernet port 9、DVI/HDMI/VGA output Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 9: Led Indicators
DC220/230·User Manual 3.3 Led indicators Name COLOR STATUS DESCRIPTION Powered up POWER No power supplied Device is working GREEN Device is starting up Network connected LINK GREEN Device disconnected or starting up Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 10: Installation And Connection
4.2.1 Connect SDI displayer Using SDI cable to connect SDI output interface with SDI displayer Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 11: Connect Dvi Displayer
(recommended); By DVI to HDMI adaptor with HDMI cable to connect. 4.2.4 Connect VGA displayer Using DVI to VGA adaptor connected to DVI interface, then with VGA cable to displayer. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 12: Connect Analog Audio Signals
4.4 Connect network Connect one end of the network cable to the decoder Ethernet port, the other end is connected to the network switch or the computer's Ethernet port. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 13: Login And Network Configuration
"Login". Note: Due to the browser compatibility issues, it may cause the web page display abnormal, it is recommended to use Chrome and Firefox. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 14 DC220/230·User Manual After normal login, decoding parameters and functional parameters can be set on the web page of decoder. The decoder page is shown in the following figure: Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 15: Network Configuration
DHCP may change. The manually specified IP addresses can be fixed to facilitate device management. The configuration of IP address should be based on the actual situation of local network. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 16 IP address is manually configured or modified, otherwise the IP address may be lost. If you want to save the configuration immediately, you can restart the device once on the WEB page. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 17: Function Configuration
First of all, we need to get the correct video source URL address from other platforms. The abnormal video source address will cause the device to not work properly. (Video source can be tested by VLC player.) Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 18: Add Srt Source
Binding Network RTP protocol usage,Default auto Video Coder RTP protocol usage,[PT,]CODER[/Timestamp-unit],i.e.96,H264/90000 RTP protocol usage, Audio Coder [PT,]CODER[/Timestamp-unit/channels],i.e.96,MPEG4-GENERIC/48000/2 6.1.1.2 Add SRT source Add a SRT source in the page of video decoder by "Media"–"Add Source"–"SRT". Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 19: Video Sources List
Click on the "Detail" button in the upper right corner to set the bit rate and resolution of each video source to be displayed or not to be displayed. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 20 IP address of the video sources.The button in the lower left corner is the "Delete" video source button, and the button in the lower right corner is the "Setup" button. The Settings button can be modified for the parameters of the video source. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 21: Video Output Setting
This window is only an operation window, which can not preview the decoded video output. If you want to watch the decoded output video, you need to connect DVI / HDMI / VGA or SDI display for viewing. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 22 32K/44.1K/48KHz dual channel is optional. Please choose according to actual needs, default 48KHz. Display current video source information It can display the current output of the video source name, current bit rate and other parameters. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 23 (that is, the same URL video source), you just need to create a new video source name, using the same URL, when setting the splitting screen, different splitting areas can choose different names of the video source. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 24: System Setup
6.2.2 System Time Timing mode can be set: synchronization with current PC, manual timing and slave NTP server.Choose the right time zone to ensure the correct time from the NTP server. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 25: Reset
(depending on the size of firmware and network environment). After the device is restarted, you can click on the upper right button to see if the software version is consistent with the planned upgrade. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 26 DC220/230·User Manual Thank you for reading. Changsha KILOVIEW Electronics CO.,LTD. Service Hotline：86-731-88315979 Website ：en.kiloview.com Technical support Email：support@kiloview.com WhatsApp: +86-18573195156/18573195256 Skype:kiloview-support/keqiu wang Address: 188#, Middle Huanbao Rd, Yuhua District, Changsha, Hunan Province, China Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
