- Page 1 ® N3 for NDI 3G-SDI/NDI Bi-Directional Converter USER MANUAL CO.,LTD. Changsha KILOVIEW Electronics...
- Page 2 Legal Notices Subject to the receiving of this document from Changsha Kiloview Electronics Co., Ltd.,(Hereinafter referred to “Kiloview”), the following terms are understood and agreed. Or else, please stop using this document. This document is copyright of Kiloview, all rights reserved. The document covers the proprietary information of the company.
-
Page 3: Table Of Contents
COTENTS 1 PRODUCT INTRODUCTION................................2 1.1 P ................................3 RODUCT EATURES ..............................4 1.2 T ECHNICAL ARAMETERS 2 USER GUIDE....................................5 3 PACKING LIST AND INTERFACE DESCRIPTION..........................6 3.1 P ..................................6 ACKING .....................................6 3.2 I NTERFACE ..................................8 3.3 L ED INDICATORS 4 INSTALLATION AND CONNECTION.............................. 8 4.1 C ...............................8 ONNECT... -
Page 4: Product Introduction
NDI This converter is small and compact enough to put in your pocket. N3 for NDI® supports up to 1080P60 video input (Encoder) or video output (Decoder). A tally system with a big tally light is built-in for indicating which camera is in program or preview. -
Page 5: Product Features
NDI high quality coding ensures excellent picture quality, lossless audio coding ensures high fidelity sound quality. Precise clock and intelligent algorithms ensure frame synchronization and accurate video and audio synchronization. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 6: Technical Parameters
Support PTZ control Tally Support Voice Intercom Support (Customization) Management type Web control Threaded Screw Standard 1/4” screw(6.5mm) Power Supply DC 5V-18V or POE Power consumption Working temperature -20℃~45℃ Dimension 100x80x24mm Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 7: User Guide
NDI sources in the same network segment, and select the source to decode and output to the monitor. You can also decode and output by means of manually adding NDI sources across network segments or NDI sources from non-default group. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 8: Packing List And Interface Description
3 Packing List and Interface Description 3.1 Packing List 3.2 Interface 1.TYPE-C expansion port 2.Tally 3.Working indicator 4.1000M Ethernet(PoE) 5.SDI output 6.SDI input 7.Audio port 8.TYPE-C power port 9.Small Tally light Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 9 N3 for NDI·USER MANUAL 10.Reset button Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 10: Led Indicators
Connect the SDI signal from a source (such as a camera) to the SDI input of the device through a cable. The SDI output is connected to the display device via one SDI cable. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 11: Connect Network
You can also connect directly to the network port of the computer. Connect Audio Using a 3.5mm interface headset with a Microphone to connect to the device or connecting 3.5mm analog audio (Note: Voice intercom function not realized in this version). Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 12: Connect Power Supply
After connecting the power adapter (DC 5V), the power light will be on and the device starts working. If your switch supports PoE, there is no need to connect to the power supply. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 13: Login And Network Configuration
For the first login or the first login after restoring the factory settings, you will need to agree to the “EULA” that pops up. Otherwise, the NDI stream service cannot be used normally. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 14: Network Configuration
IP address, Gateway and DNS according to this LAN. Click “Network” to view the device Ethernet address configuration and Failsafe address The Failsafe address is the default management IP address. Generally, you do not need to make special settings. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 15 To set the IP manually, you need to enter a fixed IP to the encoder, and this IP address is fixed as long as the encoder does not restore factory settings, this method is more stable. Therefore, each method has its own advantages, and can be selected accordingly. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 16: Local-Link (Failsafe)
This address can be changed manually (Usually no need to change), the default address is 192.168.1.168. Note: When accessing the device by Failsafe address, your computer must have an IP address of the same network segment. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 17: Ndi
N3 for NDI·USER MANUAL 6 NDI N3 for NDI converter is a professional video encoding/decoding device for NDI video production. It can convert SDI video source into NDI stream and transmit video through Ethernet for any compatible systems, devices or software in the network. -
Page 18: Ndi Discovery And Connection
Note: After opening the selected video of the converter by Studio Monitor, click in the lower right corner of the player to open the Webpage of the converter directly, which is convenient for the management of the converter. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 19: Ndi Encode Bitrate
NDI stream may not be automatically discovered NDI stream. 6.3 NDI Encode Bitrate The N3 device transmission requires high bit rate, so the device needs to be connected to a Gigabit network. The pulling stream device also needs a Gigabit network. Otherwise, the stream play will be abnormal or not smooth. -
Page 20: Encoding Parameter Configuration
NDI channel name: When there are multiple NDI sources in the same network, as the default channel names are the same, so it’s required to modify the channel name with different parameters to identify each device correctly. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 21: Advanced Settings
The device supports PTZ control, both protocol types of PTZ over Ethernet and serial port are supported. PTZ over Ethernet needs to correctly configure the protocol address and port of the connected PTZ, and specify the PTZ control protocol (Sony Visca, Pelco-D/P supported). Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 22 USB to RS232/RS422/RS485 adaptor, the device supports PTZ control over serial port. After configuring the control parameters correctly, PTZ control service can be realized by PTZ control panel of NewTek Studio Monitor (Note: It is not available in this version) Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
-
Page 23: Ndi Decoding Configuration
NDI stream for discovery, and the channel name is “Decoding Channel”. Using Studio Monitor to connect the NDI stream and click the gear button in the lower right corner to go to the WEB page. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 24: Discover Ndi Source
"Group" box, and then click "OK" (no need to fill in the IP address), the device will search for the NDI sources of these two group names at the same time. (You are allowed to add multiple group names to search) Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 25: Decoding And Output
There is a blank output box in decoding preset, if switching to a source without video output, the device will output the set color. It can also be used for testing the output to the monitor by choosing different color. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 26: Decoding Parameters Setting
If the current decoding source is disconnected, a warming notice will be displayed at the up-right corner showing the device is offline. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 27: System Settings
"Quick reset" is used to reset the coding service. It is usually applied after the parameters modifications to take effect immediately or abnormal encoding/decoding. It takes about 3 seconds and current coding service will be interrupted. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... -
Page 28: Reboot
If you need help, please contact our technical support to complete the upgrade. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved... - Page 29 WEB page to confirm whether the current software version and the latest upgrade package are the same, to make ensure the device upgrading is successful. Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
- Page 30 Thank you for reading! Changsha KILOVIEW Electronics CO.,LTD. Tel: 86-731-88315979 Website: en.kiloview.com Technical support Email: support@kiloview.com Skype: kiloview-support/keqiu wang WhatsApp: +86-18573195156/18573195256 Address: 188#, Middle Huanbao Rd, Yuhua District, Changsha, Hunan Province, China Copyright © Changsha KILOVIEW Electronics CO.,LTD. All rights reserved...
