- Page 1 Operating manual D i a g n o s t i c c a b l e V A S 5 5 8 1 A / 1 1 33.VW.2210.2779_BA_V01_EN VAS 5581A/11...
-
Page 2: Legal Notice
Symbols for warnings, prohibitions, mandatory actions and standards are taken from publicly accessible sources, such as the Internet. CAD product images and product photos are provided by the manufacturer. Images showing the product in use are provided with a reference to the source. 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 3: Table Of Contents
PRODUCT DESCRIPTION Scope of delivery Design Symbols and connections Wiring diagram Technical data OPERATION Startup Detaching the plug connections Detaching the plug connection for the diagnostic cable (32-pin) 14 Cleaning Storage Disposal Maintenance HELP Warranty Customer service 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 4: Introduction
With extensive experience in software and hardware development, CAR-connect is your dependable partner at every production stage, from prototyping to series production. CAR-connect GmbH – Experience, Expertise and Innovation – MADE IN GERMANY 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 5: Safety
This operating manual is only valid for the following product: Item number 22102779 Designation Diagnostic cable VAS 5581A/11 Warning levels This chapter provides information about the warning levels used in this operating manual. DANGER Failure to observe the safety instructions WILL result in death or serious injury! -
Page 6: Important Safety Instructions
Defective and damaged products cannot guarantee protection against electrical voltage! • Do not let the product come into contact with chemicals! • Replace a defective or damaged product immediately! • Never attempt to repair or tamper with the product! 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 7: Intended Use
• Volkswagen ID.3 (2020 model). In this operating manual, vehicle manufacturers are exclusively defined as vehicle manufacturers in the Volkswagen Group. Any use beyond what is listed here is prohibited. Requirements for the target group Only qualified personnel may work with this product! -
Page 8: Product Description
Product description Scope of delivery Immediately check the condition of the product and the completeness of the delivery. If anything is missing or defective, please contact the manufacturer immediately. (1) Diagnostic cable (2) USB stick with operating manual 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 9: Design
Symbol Meaning Caution: Check the VAS number to ensure that you are using a suitable adapter cable. Observe the operating manual! The serial number is used in conjunction with the manufacturer part number to identify the product. 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 10: Wiring Diagram
The CE marking certifies that the product complies with all applicable European regulations and has been subjected to the prescribed conformity assessment procedure. The test seal identifies the product as having been approved for use in workshops and production facilities belonging to the vehicle manufacturer. Wiring diagram 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 11: Technical Data
Max. 2000 m No limitation. Humidity Max. 80 % up to 31° C, Max. 85 % decreasing linearly to 50 % at 40° C Condensation not permitted. Maximum permissible relative humidity: 60 % in environments with corrosive gas/air. 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 12: Operation
• Use the product only for the applications intended by the vehicle manufacturer! CAUTION Risk of damage! Plug connections lock into place when attached. • Unlock the plug connections before you detach them! (See chapter “Detaching the plug connections”) 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 13: Startup
Connect the low-voltage plug to the disconnected socket of the MEB battery you want to test. Fold the locking mechanism up until it clicks into place. This pulls the plug into the plug connection. Press the lock button in (not required). 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 14: Detaching The Plug Connections
Pull out the lock button. Press down the latch and fold down the locking mechanism until it clicks into place. This releases the plug from the plug connection. Pull the plug connection apart. The plug connection is now detached. 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 15: Cleaning
Observe the safety instructions! National and local requirements for regular testing must be observed! Test the product for proper function at intervals of no more than 24 months. Contact the manufacturer to have a professional function test performed. 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... -
Page 16: Help
Always include the serial number with any product queries. This number is found on the product. CAR-connect GmbH Am Egelingsberg 8 38542 Leiferde, Germany Phone: +49 (0) 5373 – 92197-0 Fax: +49 (0) 5373 – 92197-88 service@car-connect.cc www.car-connect.cc 33.VW.2210.2779_BA_V01_EN VAS 5581A/11... - Page 17 Volkswagen Aktiengesellschaft K-GVO-LW Group After Sales – Group Service Literature and Systems Repair Shop Equipment PO box 011/4915 38442 Wolfsburg, Germany For internal use only Subject to technical changes Edition 03 / 2021 33.VW.2210.2779_BA_V01_EN VAS 5581A/11...
