About This Document - Bosch WPH Operating Instructions Manual

RE 24851-B/06.09 | W.H; WM.H
Valve type Size
.W.10 10
.W.16 16
.W.22 25
.W.25 25
.W.32 32
H.W.10 10
H.W.16 16
H.W.22 25
H.W.25 25
H.W.32 32

1 About this document

These operating instructions are valid for Rexroth 3/2-, 4/2-, and
4/3 directional valves, pilot operated.
These instructions contain important information on the safe and appropriate as-
sembly, transport, commissioning, operation, maintenance, disassembly and
simple troubleshooting of the valve.
Read these instructions completely, especially chapter
"2 General safety instructions" on page 6 before working with the valve.
Target group of these operating instructions
The target group of these operating instructions comprises all groups of per-
sons installing, operating, servicing, and maintaining the products or systems of
Bosch Rexroth.
Product scope
Table 1: Main product features
Component Max. operating pressure
series A, B, P
4X 280 bar
7X 280 bar
7X 280 bar
6X 280 bar
6X 280 bar
4X 350 bar
7X 350 bar
7X 350 bar
6X 350 bar
6X 350 bar
Bosch Rexroth AG
About this document
Max. operating pres- Max. flow
sure T
280 bar 160 l/min
250 bar 300 l/min
250 bar 450 l/min
250 bar 700 l/min
250 bar 1100 l/min
315 bar 160 l/min
250 bar 300 l/min
250 bar 450 l/min
250 bar 700 l/min
250 bar 1100 l/min
5/40
