ADDAC207 INTUITIVE QUANTIZER
Revision.05 April.2021
Image 1
ADDAC SYSTEM page 18
Ex. V
INTUITIVE MENU
REACT.T. - Reaction Time Operation
Default value is 700 miliseconds (Button 2).
This setting is independentely saved and kept safe in non-volatile memory.
This setting is used to adjust the way the Menu responds to the User input, how
long the User needs to Hold buttons to enter in the Menu Windows and how
long it will take for the menu buttons to be idle until the module automatically
exits to the Main Window.
So let's imagine we have already pressed the
second and entered in its Menu Window, the Menu Buttons already changed to
the configuration shown in image 1, displaying the default setting for Menu
Reaction Time or Button 2.
As in previous Menu Windows, pressing another Button selects it, pressing it a
second time Saves the setting in the non-volatile memory and Exits to the Main
Window.
Below is a table with the times defined by the Menu Buttons:
Hold Time
BUTTON 1 500 ms
BUTTON 2 700 ms
BUTTON 3 900 ms
BUTTON 4 1100 ms
BUTTON 5 1300 ms
BUTTON 6 1500 ms
BUTTON 7 1700 ms
BUTTON 8 1900 ms
BUTTON 9 2100 ms
BUTTON 10 2300 ms
BUTTON 11 2500 ms
BUTTON 12 2700 ms
The Hold Time value shown on the table above, triples while in KEYBOARD Mode,
so Hold Time * 3. By slowing this reaction time when the User is most likely to
be playing the keyboard it adds some extra time proven to avoid entering
unwanted Menu Windows.
USER'S GUIDE
- Buttons 1 to 12
REACT.T. Button for aprox. 1
Idle Time
5000 ms
6000 ms
7000 ms
8000 ms
9000 ms
10000 ms
11000 ms
12000 ms
13000 ms
14000 ms
15000 ms
16000 ms
