- Page 2 ADDAC213A Assembly Guide November.2017 Parts included in the kit: 2x Front Panel 2x Pcb 4x 10mm female/female spacer 8x M3 fiber washer 12x M3 screws 4x Nutted Jacks 12x No-nut Jacks 4x Jack nuts 4x 2x5 IDC Connector 2x 2x13 IDC Connector...
- Page 3 ADDAC213A Assembly Guide STEP 1: Locate Pcb and panels. The Kit contains the 213A modules pair: Left and Right module. Here’s how you can identify which is which. LEFT PAIR RIGHT PAIR CHANNEL 1 JACKS ORIENTATION JACKS ORIENTATION ADDAC SYSTEM...
- Page 4 ADDAC213A Assembly Guide We’ll now assemble the Right Module, you can follow the same principles to assemble the Left module. STEP 1: Locate pcb and place the 2x5 IDC boxed headers, notice the orientation of the headers below. After placing proceed to solder it’s pins.
- Page 5 ADDAC213A Assembly Guide STEP 3: Locate the jacks and cut the smallest legs like shown below. We’ll now populate all front panel parts: DO NOT SOLDER ANY PART UNTIL THE LAST STEP! STEP 4: Next we’ll place the threaded jacks on both ends.
- Page 6 ADDAC213A Assembly Guide STEP 6: Locate the right panel and proceed by placing it. STEP 7: Tighten both top screws and jack nuts. ADDAC SYSTEM page 6...
- Page 7 ADDAC213A Assembly Guide STEP 8: We’ll now start soldering, first solder 1 pin of the 2x13 IDC, try soldering it as raised as possible, like shown below. STEP 8: Finally solder all other pads. Congratulations, you’re all done! ADDAC SYSTEM...
-
Page 8: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC213A ASSEMBLY GUIDE Revision.01 November.2017...
