ADDAC705 Assembly Guide November.2019 ADDAC SYSTEM page 2...
Page 3
ADDAC705 Assembly Guide STEP 1: Grab the pcb and the capacitors, proceed to solder them, notice the orientation below. Tip: soldering these caps is easy, just place a dab of solder on the pad on your right (left pad if you’re left handed) and then, with the help of a tweezer, put the capacitor in place and reflow the previously tinned pad to reflow the solder while pushing the capacitor down.
Page 4
ADDAC705 Assembly Guide STEP 2: Next place the power rails 2x5 boxed header, notice the orientation of the header below. ADDAC SYSTEM page 4...
Page 5
ADDAC705 Assembly Guide STEP 3: Next place the 2 diodes. Notice the orientation marked on the pcb. ADDAC SYSTEM page 5...
Page 6
ADDAC705 Assembly Guide STEP 4: Next we’ll need to prepare some parts before adding them to the front panel. Locate the jacks and cut the smallest legs like shown below. STEP 5: Locate the rotary switch and trim the middle legs like shown below.
Page 7
ADDAC705 Assembly Guide STEP 6: Place all parts on the pcb, notice the values, orientation and jack types like shown below. A10K B10K B100K B10K Notice Orientation “Round” side facing right! Non-threaded Jacks Threaded Jacks Non-threaded Threaded Jacks Jacks ADDAC SYSTEM...
Page 8
ADDAC705 Assembly Guide STEP 7: Place the frontpanel and tighten all nuts. ADDAC SYSTEM page 8...
Page 9
ADDAC705 Assembly Guide STEP 8: Adjust the height of the pcb keeping it parallel to the front panel. ADDAC SYSTEM page 9...
Page 10
ADDAC705 Assembly Guide STEP 9: Solder all parts. ADDAC SYSTEM page 10...
Page 11
ADDAC705 Assembly Guide Finish it by placing the knobs and you’ve finished the assembly process! ADDAC SYSTEM page 11...
