Summary of Contents for Egholm City Ranger 2200
- Page 1 ’ peratOr anual GRASS COLLECTOR City Ranger 2200...
- Page 2 Introduktion Dear Customer Congratulations with your new Egholm product. The City Ranger 2200 is a Danish designed and manufactured product, which offers a very flexible way of maintaining outdoor areas. Optimal use of your City Ranger 2200 Grass Collector: To ensure the optimal performance of your City Ranger 2200 Grass Collector, please read this operator’s manual carefully before starting to use the machine.
-
Page 3: Table Of Contents
5.1 Spare parts - City Ranger 2200 Hopper for grass collecting ...... -
Page 4: General Information
Check that the hopper is securely locked onto the machine. (Picture 2) Do not get too close to the hopper: Make sure there is no one close to the machine when it is in use. Operator’s Manual City Ranger 2200 Grass Collector... - Page 5 (Picture 1) Risk of crushing: Make sure no one gets their fingers trapped when the hopper is lowered after tipping. (Picture 2) Attaching the hopper on the machine Lowering the hopper Operator’s Manual City Ranger 2200 Grass Collector...
-
Page 6: Ec Declaration Of Conformity
· has been manufactured in conformity with the provisions of the Machinery Directive, Directive 2006/42/EU · has been manufactured in conformity with the provisions of the Machinery Directive, Directive 2000/14/EU Location: Lemvig Date: Signature: Knud Olsen, Senior Engineer Operator’s Manual City Ranger 2200 Grass Collector... -
Page 7: Technical Data
Tipping level from ground, Variably-adjustable from with high tipping: 575 to 1,860 mm Hydraulic oil: Texaco Rando HDZ 46 or equivalent Egholm reserves the right to alter the specifications and equipment at any time without notice. Operator’s Manual City Ranger 2200 Grass Collector... -
Page 8: Operator's Manual
Operator’s manual 2.1 Assembling the hopper frame On delivery, the frame must be assembled. Assemble with the 2 bolts (supplied) and the frame is ready for use. (Picture 1) 2 bolts on frame Operator’s Manual City Ranger 2200 Grass Collector... -
Page 9: Attaching The Hopper
Push the lever to level 2, push down, then push the locking pin away from the barb (Picture 4) and lower the hopper slowly down over the machine. Attaching the hopper Locking pin Lever Operator’s Manual City Ranger 2200 Grass Collector... - Page 10 Keep a secure grip of the hopper frame lever when the hopper is lowered. The locking handle is turned Removing the hopper: Follow the procedure for attaching in reverse order. Operator’s Manual City Ranger 2200 Grass Collector...
-
Page 11: Checks Before Start-Up
Do not drive the machine where it can slide, tip or roll. Do not drive on slopes with an incline of more than 10°. (Picture 4) Closing rear cover Max. 10° Do not drive on slopes with an incline of more than 10° Operator’s Manual City Ranger 2200 Grass Collector... -
Page 12: Grass Collector Start-Up
(Picture 4) Weight distribution 6. Move throttle to full. Please refer to Rotary Mower safety instructions in the Operator’s Manual for the Mulch Mower and Rotary Mower. Throttle PTO front PTO rear Operator’s Manual City Ranger 2200 Grass Collector... -
Page 13: Emptying The Hopper
Note that the rear cover opens automatically when the hopper is tipped at an angle of about 30°. (Picture 4) The hopper is raised to max. height and tipped as far back as possible. Operator’s Manual City Ranger 2200 Grass Collector... -
Page 14: Adjustment
The exhaust air can be adjusted either to blow upwards or downwards. To adjust the air direction: turn the vent in the exhaust- air grate. Loosen the bolts at both sides, turn the vent as required and retighten the bolts. (Picture 1) Operator’s Manual City Ranger 2200 Grass Collector... -
Page 15: Leaf Vacuum Hose For Hopper (Optional Equipment)
(Picture 3) 1. Position the sealing ring on top of the collar of the change-over valve housing. 2. Place the strip supplied around the sealing ring and tighten. Cut off the loose end. Operator’s Manual City Ranger 2200 Grass Collector... - Page 16 Position in relation to the right-hand square hole: · 60 mm to the left of the centre of the hole. · 100 mm above the centre of the hole. (Picture 4) Hole may be missing Operator’s Manual City Ranger 2200 Grass Collector...
-
Page 17: Fitting The Leaf Vacuum Hose
9. Fold the handle in. 10. Attach the rubber strap to the handle. (Picture 4) To remove the Leaf vacuum hose, reverse the procedure. Place the vacuum nozzle in the holder Attach rubber strap to the handle Operator’s Manual City Ranger 2200 Grass Collector... -
Page 18: Using The Leaf Vacuum Hose
There is a hook on the extension arm on which the handle can be placed when the Leaf vacuum hose is not in use. (Picture 4) Loosen the screw, pull out, tighten the screw Extension arm Hook for handle Operator’s Manual City Ranger 2200 Grass Collector... - Page 19 1. Turn the Leaf vacuum hose towards the back of the machine. 2. Lock it with the transport lock, by flipping the transport lock up under the Leaf vacuum hose. (Picture 1) Operator’s Manual City Ranger 2200 Grass Collector...
-
Page 20: Service And Maintenance
The rear cover can be opened without tipping the hopper. 1. Pull back the pin under the hopper. 2. The rear cover can now be opened from the bottom. (Picture 4) Opening the rear cover Operator’s Manual City Ranger 2200 Grass Collector... -
Page 21: Maintenance
3.3 Troubleshooting The hopper suction does not work. Possible causes: 1. The hopper is full. 2. The grass filter is blocked and must be cleaned. (See section 3.1 Cleaning) Operator’s Manual City Ranger 2200 Grass Collector... - Page 22 7. Grass can amass on the rear cover and can mean that the rear cover will not close. Clean dried-on grass off the rear cover. 8. Certain types of grass and leaves tend to cause frequent blockages. Operator’s Manual City Ranger 2200 Grass Collector...
- Page 23 3. Turn off the rear PTO and lift the hopper up to check whether there is anything blocking the change-over valve. If there is, remove it. If there is still no suction, remove the Leaf vacuum hose and check whether anything is blocking the hose. Operator’s Manual City Ranger 2200 Grass Collector...
-
Page 24: Conditions
The warranty period for the materials and manufacture of the Grass Collector is 12 months from the date of purchase. In case of errors or defects on the machine within the warranty period, Egholm A/S will carry out the necessary repairs without charge for materials and working hours in accordance with the terms and conditions listed below. -
Page 25: Complaints
1. Used hydraulic oil is to be disposed of at an approved waste disposal facility or site. 2. Remove all plastic and rubber parts and discard appropriately. 3. After the parts mentioned have been removed, the machine is ready to be handed over to an approved scrap merchants. Operator’s Manual City Ranger 2200 Grass Collector... -
Page 26: Spare Parts
Spare parts 5.1 Spare parts - City Ranger 2200 Hopper for grass collecting 09723970 Seal 61202220 Top grate - ø5 61202539 Top grate - ø10 41108390 Shield 09724320 Tank holder 41202350 Turbine 61201975 Cover Operator’s Manual City Ranger 2200 Grass Collector... -
Page 27: Spare Parts - City Ranger 2200 Leaf Vacuum Hose
Spare parts 5.2 Spare parts - City Ranger 2200 Leaf vacuum hose 70501131 Vacuum hose, 6 m 70501151 Kit – Pipe bend 70501221 Kit - Sealing ring 09724090 Nozzle 70501161 Kit – Pipe 70501171 Kit – Top support 70501181 Kit – Bottom support... - Page 28 Egholm A/S Transportvej 27 DK-7620 Lemvig T. +45 97 81 12 05 F. +45 97 81 12 10 www.egholm.eu info@egholm.eu 70101191-01 EN...
