Proctology support 11233
Proctology support 11233 including versions
Version
11233
11233-1
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-19
Document number: M11233EN rev.01
1
Description
Proctology support with knee pad 500 x 300 mm
Proctology support with knee pad 500 x 500 mm
Advertisement
Table of Contents
Related Manuals for Reison 11233
Summary of Contents for Reison 11233
- Page 1 Proctology support 11233 Proctology support 11233 including versions Version Description 11233 Proctology support with knee pad 500 x 300 mm 11233-1 Proctology support with knee pad 500 x 500 mm Warning! This symbol indicates important information related to safety. Follow these instructions carefully.
- Page 2 Intended use Proctology support for support and positioning of patient placed in “Pray position” during surgery. The product is to be used by medical professionals within a medical facility. Safety regulation Maxumum load: 200 kg, corresponding to a patient weight of 325 kg, according to EN 60601-1 and EN 60601-2.
- Page 3 User instruction Installation The proctology support is mounted to the end of the operating table using an adaptor (not included). The adaptor can be mounted on the proctology support using the included adaptor plates. Position adjustment...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
- Page 5 Spare parts...
- Page 6 Version: 11233 11233-1 Description Pcs. Article no. Article no. Frame 11237 11237 Lifting screw 40050 40050 Flange bearing 14/16x12 Shaft 11244 11244 Bevel gear 40052 40052 Tubular pin FRP Ø4x25 Abdomen support 10668 10668 Screw MC6S M6x70 FZB Washer BRB 6,4x17x3...
- Page 7 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
