Foot support 10-296
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-05-03
Document number: M10-296EN rev.01
1
Advertisement
Table of Contents
Related Manuals for Reison 10-296
Summary of Contents for Reison 10-296
- Page 1 Foot support 10-296 Warning! This symbol indicates important information related to safety. Follow these instructions carefully. Read User Manual before use! It is important to fully understand the content of the user manual before attempting to use the equipment. 2021-05-03...
- Page 2 Intended use Foot support for support and positioning of patient’s feet during surgery. The product is to be used by medical professionals within a medical facility. Safety regulation Maximum load: 25 kg, corresponding to a patient weight of 200 kg, according to EN 60601-1 and EN 60601-2.
- Page 3 User instruction Installation Position adjustment...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
- Page 5 Spare parts Description Pcs. Article no. Rail fitting Right 11580 Bracket Right 11583 Foot plate 11584 Knob VCT.43-p M8x16 soft 10895 Locking handle 10733 Plastic plug IFR 25x25x2 Rail fitting Left 11580-1 Bracket Left 11583-1 Spacer 05-8-12-3 Ball K20M8S Technical specification Maximum workload 25 kg, corresponding to a patient weight of 200 kg, according to EN 60601-1 and EN 60601-2...
- Page 6 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
