CHECK GAS TYPE
Be sure your gas supply is right for your heat-
er. Otherwise, call dealer where you bought
the heater for proper type heater.
CLEARANCES TO
COMBUSTIBLES
Carefully follow the instructions below. This
heater is a freestanding unit designed to be
mounted on a wall or set on a base.
WARNING: Maintain the
minimum clearances shown in
Figure 4. If you can, provide
greater clearances from floor,
ceiling, and joining wall.
CEILING
6"
Minimum
From
Sides of
Heater
Left
Side
2" Minimum to Top Surface of Carpeting,
Tile or Other Combustible Material
FLOOR
Figure 4 - Mounting Clearances as
Viewed From Front of Heater
LOCATING HEATER
This heater is designed to be mounted on a
wall. For convenience and efficiency, install
heater:
1. Where there is easy access for operation,
inspection, and service.
2. In the coldest part of room.
10
INSTALLATION
FASTENING HEATER TO WALL
The mounting bracket is located on back panel
of heater (see Figure 5). It has been taped
there for shipping. Remove mounting bracket
from back panel.
Figure 5 - Mounting Bracket Location
Removing Front Panel of Heater
1. Remove two screws near bottom corners
36"
Minimum
of lower front panel.
2. Pull bottom of lower front panel forward,
then down (see Figure 6).
Right
Side
Figure 6 - Removing Front Panel Of
www.usaprocom.com
Mounting Bracket
Mounting Bracket
Heater
200213-01C
