Valcourt SRF40 Owner's Manual

Direct vent zero clearance gas fireplace heater
Hide thumbs Also See for SRF40:

Advertisement

Quick Links

Safety tested
according to ANSI Z21.88-2017
and CSA 2.33-2017 standards
by an accredited laboratory.
FIRE OR EXPLOSION HAZARD
• Failure to follow safety warnings exactly could result in
serious injury, death or property damage.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL
COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier
designed to reduce the risk of burns from the hot viewing glass is provided
with this appliance and shall be installed for the protection of children and
other at-risk individuals. NOTE : Barrier required, may be sold separately.
WARNING
MULTIFUNCTION REMOTE (MF)
DANGER
WARNING
• If not installed, operated and maintained in accordance
with the manufacturer's instructions, this product could
expose you to substances in fuel or from fuel combustion
which can cause death or serious illness.
• This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only) or
mobile home, where not prohibited by local codes.
• This appliance is only for use with the type of gas
indicated on the rating plate.
• This appliance is not convertible for use with other
gases, unless a certified kit is used.
• Fuels used in gas, wood-burning or oil fired appliances, and
the products of combustion of such fuels, contain chemicals
known to the State of California to cause cancer, birth defects
or other reproductive harm. For more information go to
www.P65warnings.ca.gov/
OWNER'S
MANUAL
MODEL
SRF40
(FG00002 & FG00020)
DIRECT VENT
ZERO CLEARANCE
GAS FIREPLACE HEATER
46195U_A
2021-11-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRF40 and is the answer not in the manual?

Questions and answers

Summary of Contents for Valcourt SRF40

  • Page 1 OWNER’S MANUAL MODEL SRF40 (FG00002 & FG00020) DIRECT VENT ZERO CLEARANCE GAS FIREPLACE HEATER MULTIFUNCTION REMOTE (MF) Safety tested according to ANSI Z21.88-2017 and CSA 2.33-2017 standards by an accredited laboratory. DANGER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED.
  • Page 2 Dealer: Installer: Phone Number: Serial Number:...
  • Page 3 If it cannot be provided, the warranty period will be determined by the date of manufacture of the product. It is also highly recommended to register the warranty online at https://www.valcourtinc.com/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit. Owner’s Manual - SRF40 Page 3...
  • Page 4 Page 4 Owner’s Manual - SRF40...
  • Page 5: Table Of Contents

    Gas valve ........................31 Maintenance Frequency ....................34 Maintenance venting ......................35 Troubleshooting ....................... 36 Control System Troubleshooting ..................38 8. Parts View ans Parts List ...................... 40 Appendix 1: Accessories ......................44 Waranty ............................ 46 Owner’s Manual - SRF40 Page 5...
  • Page 6: Certification Plate

    CERTIFICATION PLATE Page 6 Owner’s Manual - SRF40...
  • Page 7: Safety Information

    Do not abuse the glass by striking or hitting it. WARNING Do not use ammonia based or abrasive cleaners on glass. Do not attempt to clean glass when glass is hot. Owner’s Manual - SRF40 Page 7...
  • Page 8: Carbon Monoxide Poisoning Hazard

    After it has been determined that each appliance connected to the venting system properly vents when tested as outlined above, return doors, windows, exhaust fans, fireplace dampers and any other gas-fired burning appliance to their previous conditions of use. Page 8 Owner’s Manual - SRF40...
  • Page 9: Safety Information For Users Of Propane Gas

    Odorants in Propane Gas also are subject to oxidation. This fading can occur if there is rust inside the storage tank or in iron gas pipes. Owner’s Manual - SRF40 Page 9...
  • Page 10 Always be sure your container is under vapor pressure by turning it off at the container before it goes completely empty or having it refilled before it is completely empty. Page 10 Owner’s Manual - SRF40...
  • Page 11: General Information

    Do not put furniture or any other combustible hosehold Be careful not to put any decorating objects objects within 36" of the fireplace front. sensitive to heat too close above or around the fireplace was it gets very hot when operating. Owner’s Manual - SRF40 Page 11...
  • Page 12: Fuel

    Odor risk with polymer materials Do not install any cement boards of other materials that contain polymer based fibers or other polymer materials. Page 12 Owner’s Manual - SRF40...
  • Page 13: Lighting Instructions

    TO TURN OFF GAS TO APPLIANCE Turn off all electric power to the appliance Locate On/Off gas shut-off and turn if service is to be performed (if applicable). clockwise to OFF. Do not force. Owner’s Manual - SRF40 Page 13...
  • Page 14: Operating Instructions

    NOTICE: The variable halogen lighting and blower features will not operate during a power outage. NOTICE: Replace all batteries at least once each year, preferably before at the beginning of the season. Page 14 Owner’s Manual - SRF40...
  • Page 15: Noise Coming From The Fireplace

    The wall control switch should be turned OFF when the fireplace is not being used for extended periods of time. Turned on For use of the multifonction remote REMOTE Turned off Program (Pairing) Owner’s Manual - SRF40 Page 15...
  • Page 16 2- With a multifunction thermostatic Remote (Transmitter) ON/OFF/SMART Button Technical Data - Remote Control Supply voltage 4.5 V (three 1.5 V AAA batteries) Ambient temp. ratings 0-50°C (32 - 122°F) Radio frequency 315 MHz Page 16 Owner’s Manual - SRF40...
  • Page 17 With the batteries already installed in the transmitter, push the ON/OFF button. The receiver will beep four times to indicate the transmitter’s command is accepted and sets to the particular code of that transmitter. The system is now initialized. Owner’s Manual - SRF40 Page 17...
  • Page 18 With the system ON, press the ON/OFF button on the transmitter. The transmitter LCD display will only show the room temperature. At the same time, the receiver will turn off the fireplace. A single beep from the receiver confirms reception of the command. Page 18 Owner’s Manual - SRF40...
  • Page 19 A single beep will confirm reception of the command. Flame OFF Flame Level 1 Flame Level 5 Flame Level Maximum Owner’s Manual - SRF40 Page 19...
  • Page 20 Controls»). To adjust the set temperature, press the up or down arrow buttons until the desired set temperature is displayed on the LCD screen of the transmitter. Note: When Smart Thermostat is activated, manual flame height adjustment is disabled. Page 20 Owner’s Manual - SRF40...
  • Page 21 SPLIT FLOW mode. Pressing the Up Arrow Button will activate the secondary burner. Pressing the Down Arrow Button will turn the secondary burner off. A single “beep” will confirm the reception of the command Owner’s Manual - SRF40 Page 21...
  • Page 22 Install batteries (Pairing the remote step one, «Pairing the remote», page 17) In case of power loss, the fireplace will switch to battery mode automatically. The fireplace will operate normally without the blower or light control when in battery mode. Page 22 Owner’s Manual - SRF40...
  • Page 23 • Turn the system power supplies (to the wall control or remote control) OFF for two or three seconds and then restoring a power supply back on. The return of the system to normal operation must be checked under safe conditions by the user and/ or service personnel. Owner’s Manual - SRF40 Page 23...
  • Page 24: Maintenance And Service

    The glass door is wide and heavy and can be difficult to install or remove by a single person. It is recommended that two people remove the glass door. CAUTION Sharp objects. Gloves are strongly recommended. Page 24 Owner’s Manual - SRF40...
  • Page 25: Glass Cleaning

    (we recommend gas fireplace glass cleaner). WARNING Clean glass with cleaner designed for fireplaces. Do not use Ammonia based or abrasive cleaners on glass. Do not attempt to clean glass when glass is hot. Owner’s Manual - SRF40 Page 25...
  • Page 26: General

    The fireplace and venting system should be inspected before initial use and at least annually by a qualified service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the air flow. Page 26 Owner’s Manual - SRF40...
  • Page 27: Inspection

    • Keep burner and control compartment clean. • Examine venting system periodically and replace damaged parts. • Make a periodic visual check of pilot and burners. Clean and replace damaged parts. Owner’s Manual - SRF40 Page 27...
  • Page 28 - Inspect the venting and vent termination cap for damage, corrosion, sooting, or obstruction and correct if present. - Check all accessible gas-carrying tubes, connections, pipes and other components for leaks. • In addition, clean and inspect the fireplace following any remodeling work in your home. Page 28 Owner’s Manual - SRF40...
  • Page 29: Light Bulbs Replacement

    Use gloves to avoid touching the bulb with bare hands. 1. Remove the following items: • Invisimesh barrier (See Homeowner’s Manual, Maintenance and Service) • Glass door Assembly (See Homeowner’s Manual, Maintenance and Service) • Liners (See separate liner instruction document). Owner’s Manual - SRF40 Page 29...
  • Page 30 6. Remove protective connectors on Wire Assembly from fireplace and discard. Connect Wire Harness to both blowers and the other end to the Wire Assembly supplied with the fireplace. TO WIRE ASSEMBLY (MODULE) TO WIRE ASSEMBLY (MODULE) Page 30 Owner’s Manual - SRF40...
  • Page 31: Gas Valve

    Notice: Always turn off gas and electrical supply to the fireplace before servicing the controls. Remove the following items: • Barrier Screen (See Maintenance and Service section for Instructions). • Glass Frame Assembly (See Maintenance and Service section for Instructions). Remove the log set and set aside. Owner’s Manual - SRF40 Page 31...
  • Page 32 5/16" Remove the side liner panel located to the right. If applicable, loosen the 2 screws holding the 5/16" right liner panel bracket then remove it. Remove Access Panel. 5/16" Page 32 Owner’s Manual - SRF40...
  • Page 33 Remove the screw holding the bottom of the gas valve housing. Keep the scew. Unscrew the burner gas intake tubes nuts. 5/16" 9/16" Slide out the gas valve housing. SPLIT FLOW SOLENOID VALVE GAS VALVE Owner’s Manual - SRF40 Page 33...
  • Page 34: Maintenance Frequency

    • Any control should be replaced if it does not perform properly on checkout or service. In addition, replace any module if it is wet or looks like it has been wet. Page 34 Owner’s Manual - SRF40...
  • Page 35: Maintenance Venting

    Venting termination shall not be recessed into a wall or siding. Slide the vertical vent cap over the ends of the vent pipe and secure. Slide the vertical vent cap over the ends of the vent pipe and secure Owner’s Manual - SRF40 Page 35...
  • Page 36: Troubleshooting

    Clogged or dirty burner ports Clean burner ports Blocked orifice Check orifice opening Burner does not light but Loose wire connections Check valve/control module connections pilot remains on Faulty pilot Replace pilot Faulty valve Replace valve Page 36 Owner’s Manual - SRF40...
  • Page 37 Whistle noise from fireplace Open control knob to full position position Spiral gas flex line pinched or Straighten flex line where pinched or replace too small diameter line gas feed line with larger diameter Owner’s Manual - SRF40 Page 37...
  • Page 38: Control System Troubleshooting

    Ev1 terminal and the ground connection on the valve body. If the voltage is greater than 0 then Replace Valve. Otherwise replace IFC. Replace the pilot assembly. Spark continues while the pilot is ON. Replace the IFC board. Page 38 Owner’s Manual - SRF40...
  • Page 39 Verify that the main burner flame modulates. If it does not modulate, replace the gas valve. Main burner modulates Verify that the gas valve outlet pressure limits are in accordance with the manufacturer properly? specifications. If not, replace the gas valve. Owner’s Manual - SRF40 Page 39...
  • Page 40: Parts View Ans Parts List

    8. Parts View and Parts List DETAIL C DETAIL D 48 49 DETAIL E DETAIL B DETAIL A Page 40 Owner’s Manual - SRF40...
  • Page 41 JUMPER WIRE 44219 WIRE HARNESS RECEIVER - PROFLAME 2 60400 MODULE WIRE CONNECTOR 49176 PROFLAME II MODULE (LP) 44209 FUSE GLASS 3.15A / 250V (5 X 20) 44217 4 POSITIONS TERMINAL BLOCK PLUG (MALE PINS) Owner’s Manual - SRF40 Page 41...
  • Page 42 SRF40 MANUAL AC04321 RUSTIC BRICK PANELS 22349 HERRINGBONE TOP LINER FOR SRF40 22380 LEFT LINER LIGHTHOUSE SRF40 22379 REAR LINER LIGHTHOUSE SRF40 22381 RIGHT LINER LIGHTHOUSE SRF40 22348 HERRINGBONE FRONT LEFT LINER FOR SRF40 Page 42 Owner’s Manual - SRF40...
  • Page 43 Part # Description 22347 HERRINGBONE FRONT RIGHT LINER FOR SRF40 AC04326 HERRINGBONE BRICK PANELS 22345 HERRINGBONE LEFT LINER FOR SRF40 22344 HERRINGBONE REAR LINER FOR SRF40 22346 HERRINGBONE RIGHT LINER FOR SRF40 AC04322 BLACK REFLECTIVE GLASS PANELS PL71282 HORIZONTAL TRIM...
  • Page 44: Appendix 1: Accessories

    APPENDIx 1: ACCESSORIES The following accessories must be purchased separately. Their installation instructions are included in their kit and can be found on Valcourt website, in the options/Accessories section of this fireplace’s page. Description Code REQUIRED ACCESSORIES Classic Wood Logs Ember and Black Glowing Wool...
  • Page 45 Owner’s Manual - SRF40 Page 45...
  • Page 46: Waranty

    **Exclusion refer to statement above. ***Labour based on predetermined chart. Shall your unit or a component be defective, contact immediately your dealer or VALCOURT customer service. Prior to your call make sure you have the following information necessary to your warranty claim treatment: Your name, address and telephone number.
  • Page 48 This document is available for free download on the Stove Builder International inc. manufacturer’s website. It is a copyrighted document. 250, rue de Copenhague, Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002...
