PREFABRICATED WOOD-BURNING FIREPLACE INSTALLATION AND OPERATION MANUAL Keep this manual for future reference Standards: ULC-S610, UL-127 E.P.A. Standards Exempt Manufactured by: STOVE BUILDER INTERNATIONAL INC. 250, rue de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3 Tel.: 418 878-3040 Fax: 418 878-3001 valcourtinc.com This manual is available for free download on the manufacturer’s web site.
GRAVITY DISTRIBUTION KIT ........................... 27 FORCED AIR DISTRIBUTION KIT .......................... 28 HEAT DISTRIBUTION SYSTEMS ........................ 3 0 VALCOURT LIMITED LIFETIME WARRANTY .................... 3 2 REGISTER YOU WARRANTY ONLINE To receive full warranty coverage, you will need to show evidence of the date you purchased your unit. Keep your sales invoice. We also recommend that you register your warranty online at http://www.valcourtinc.com/warranty-registration.aspx...
INTRODUCTION This manual contains all the information required for safe, efficient installation and use of your Valcourt fireplace. Read carefully all the instructions contained herein and keep this manual handy so you may refer to it whenever necessary. Before starting to install the fireplace, consult local authorities to obtain a construction permit and learn about all applicable regulatory requirements.
INSTALLATION Beaumont and Frontenac fireplaces are designed and approved for installation with the following brands of chimneys measuring 7” (178 mm) in diameter as well as a minimum of 15’ (4.6 m) and maximum of 45’ (13.7 m) in height.
Page 5
Choose the best location for your fireplace based on the position of the doors and windows. Provide for the positioning of the outside air inlet as well as the chimney. Remember to leave sufficient space for the hearth extension and mantel. If possible, install the fireplace where it will not be necessary to cut any floor or ceiling joists.
Page 6
Figure #2: Various Fireplace Locations Figure #3: Possible Chimney Configurations Figure #4: Fireplace Framing...
FIREPLACE INSTALLATION The table below shows the minimum chimney height requirements, fireplace included, according to the number of elbows: Chimney Number of Elbows Minimum Height Straight installation --------------- 15’ (4.6 m) 1 - 15° offset 2 - 15° elbows 15’ (4.6 m) 2 - 15°...
Page 8
Using an adjustable collar or aluminum duct tape, attach the flexible duct to the adaptor. 14. Valcourt fireplaces are equipped with an automatic or manual switch located behind the lower louver at your right. When switch is place on auto, the blower will activate when fireplace reaches minimum starting temperature 43°C (110°F).
Page 9
USING A DECORATIVE GAS APPLIANCE. THIS FIREPLACE HAS NOT BEEN TESTED WITH AN UNVENTED GAS LOG APPLIANCE. TO REDUCE THE RISK OF FIRE OR INJURY, DO NOT INSTALL A GAS LOG APPLIANCE WITHOUT A VENT PIPE. Figure #6: Beaumont Fireplace and Hearth Extension Positioning...
Page 12
12. When you build a chase enclosure for chimney sections above the roof, the chimney must extend at least 3 ft. (92 cm) above the chase enclosure and at least 2 ft. (61 cm) higher than any wall, roof or building within 10 ft.
INSTALLATION INSTRUCTION FOR MASONRY APPLICATION The following requirements must be respected: 1. The chimney must be absolutely clear of any soot residue or creosote. Check for cracks, loose or missing bricks that could inhibit correct installation of the liner. 2. The clearance to combustible must be a minimum of 1” between the outside of the masonry and any wood framing or loose insulation.
Page 14
Installation The chimney must be relined with a stainless steel liner model Tubinox or Projet SS or any other listed liner or flexible liner to ULC-S635, ULC-S640 or UL777 of the same diameter as the outlet of the fireplace. For connection at 45 angle, a special connector (BISPMA for the 7 in. chimney) must be used to connect the liner to the insulated chimney.
Page 15
Installation with an 7 in. EXCEL chimney (Figure # 8) Installing your fireplace with a masonry chimney still requires using EXCEL chimney from the top of the fireplace to the wall where it will connect to a listed liner that will run up inside the masonry chimney. The stainless steel liner should be fitted inside the clay liner all the way to the top of the masonry chimney.
FIREPLACE FINISH 1. Combustible materials can be used to finish the fireplace. The framing can be built directly on the sides of the appliance. (Figure #17) 2. Side walls can exceed the appliance’s face by a maximum of 6” (152 mm). (Figure #14) 3.
DO NOT OVERHEAT 8. Use the grate made by VALCOURT Burn only the quantity of combustible it can contain. Do not burn garbage, painted wood or wood that has been exposed to salt water. 9. Always have minimum of 1” accumulation of ashes at the bottom of the fireplace. The grate may deform if no ashes are left.
CREOSOTE When wood burns slowly, it produces tar and other organic vapors which combines with humidity to produce creosote. Creosote vapor condenses in the chimney left relatively cool by the slow fire and coats the inside of the flue with residue. When creosote ignites, it produces a red-hot, extremely dangerous fire. It is therefore recommended to make small, brightly burning fires rather than lazy, smoldering fires.
5. Handle the glass with care to avoid injury. 6. Allow to dry for 24 hours. NOTE: Never use substitute parts. Use only Valcourt brand parts. REPLACING FIRESTONE IN AN BEAUMONT FIREPLACE Do not use the fireplace with a broken or missing firestone.
HEAT DISTRIBUTION SYSTEMS Figure #19: Heat Distribution Options GRAVITY DISTRIBUTION KIT The Gravity Distribution Kit (FP4-300) may be used to heat rooms located above, behind and either side of the room where the fireplace is located. Note that, if the hot air outlets are located at various levels, the heat will tend to seek the one at the highest level.
FORCED AIR DISTRIBUTION KIT The Forced Air Distribution Kit can be used to heat adjacent rooms or lower floor located up to 50’ (15.2 m) from your Valcourt Fireplace. Only 6” (15cm) flexible isolated duct can be use for this installation. (Figure #20) If the fan is install with a rheostat, the operation is manually control.
Page 29
ATTENTION: The connection to an existing duct must follow the direction of the furnace’s airflow and be equipped with a back draft damper. (Figure #21) Both alternatives require electrical power. Make sure all electrical connections are made in the correct order and comply with local regulations as well as the applicable National Building Code standards.
Paint (peeling), gaskets, insulation, firebrick, and ceramic fibre blankets. 1 year *Pictures required Shall your unit or a components be defective, contact immediately your VALCOURT dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: ...
