Valcourt SRF40 Installation Instructions Manual

Hide thumbs Also See for SRF40:

Advertisement

Quick Links

Safety tested
according to ANSI Z21.88-2017
and CSA 2.33-2017 standards
by an accredited laboratory.
FIRE OR EXPLOSION HAZARD
• Failure to follow safety warnings exactly could result in
serious injury, death or property damage.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE
Printed in Canada
HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL
COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier
designed to reduce the risk of burns from the hot viewing glass is provided
with this appliance and shall be installed for the protection of children and
other at-risk individuals. NOTE : Barrier required, may be sold separately.
WARNING
INSTALLATION
INSTRUCTIONS
MULTIFUNCTION REMOTE (MF)
DANGER
WARNING
• If not installed, operated and maintained in accordance
with the manufacturer's instructions, this product could
expose you to substances in fuel or from fuel combustion
which can cause death or serious illness.
• This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only) or
mobile home, where it is not prohibited by local codes.
• This appliance is only for use with the type of gas
indicated on the rating plate.
• This appliance is not convertible for use with other
gases, unless a certified kit is used.
• Fuels used in gas, wood-burning or oil fired appliances, and
the products of combustion of such fuels, contain chemicals
known to the State of California to cause cancer, birth defects
or other reproductive harm. For more information go to
www.P65warnings.ca.gov/
MODEL
SRF40
(FG00002 & FG00020)
DIRECT VENT
ZERO CLEARANCE
GAS FIREPLACE HEATER
46195I_A
2021-11-10

Advertisement

Table of Contents
loading

Summary of Contents for Valcourt SRF40

  • Page 1 INSTALLATION INSTRUCTIONS MODEL SRF40 (FG00002 & FG00020) DIRECT VENT ZERO CLEARANCE GAS FIREPLACE HEATER MULTIFUNCTION REMOTE (MF) Safety tested according to ANSI Z21.88-2017 and CSA 2.33-2017 standards by an accredited laboratory. DANGER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED.
  • Page 3 To reduce the risk of fire, follow the installation instructions in this manual. Installation Manual - SRF40 Page 3...
  • Page 4: Table Of Contents

    Termination Clearances ....................39 5. Gas Connections ........................40 Gas Supply ........................40 Installing a New Shut-Off Valve ..................41 Checking Manifold Pressures ................... 42 Gas Line Connection ....................... 42 6. Electrical Connections ......................43 Page 4 Installation Manual - SRF40...
  • Page 5 Control Module Access ....................44 Wiring Diagram ........................ 45 7. Optional Traditional Gravity Hot Air Distribution Kit Installation (AC04367) ....... 47 8. Optional Modern Gravity Hot Air Distribution Kit Installation (AC04369) ......51 Appendix 1: Accessories ......................55 Installation Manual - SRF40 Page 5...
  • Page 6 CERTIFICATION PLATE Page 6 Installation Manual - SRF40...
  • Page 7: Part A - Operation

    Only doors certified with the appliance shall be reduce the risk of burns from the hot viewing used. glass is provided with this appliance and shall be installed for the protection of children and other at-risk individuals.” Installation Manual - SRF40 Page 7...
  • Page 8 After it has been determined that each appliance connected to the venting system properly vents when tested as outlined above, return doors, windows, exhaust fans, fireplace dampers and any other gas-fired burning appliance to their previous conditions of use. Page 8 Installation Manual - SRF40...
  • Page 9 Odorants in Propane Gas also are subject to oxidation. This fading can occur if there is rust inside the storage tank or in iron gas pipes. Installation Manual - SRF40 Page 9...
  • Page 10 Always be sure your container is under vapor pressure by turning it off at the container before it goes completely empty or having it refilled before it is completely empty. Page 10 Installation Manual - SRF40...
  • Page 11: General Information

    Any alteration of the original design, installed other than as shown in these instructions or use with a type of gas not shown on the rating plate is the responsibility of the person and company making the change. Installation Manual - SRF40 Page 11...
  • Page 12: High Altitude

    • Installation other than as instructed by SBI. • Improper positioning of the glass door, or decorative accessories including logs, rocks, crushed glass or other approved media. • Installation or use of any component part not manufactured or approved by manufacturer. Page 12 Installation Manual - SRF40...
  • Page 13: Specifications

    120 V, 60 HZ, 33W, 76 CFM Light Bulb replacement 35w Clear Halogen, BI-Pin 6.35 mm base, 120 vac, UL NOTICE: Air shutter settings are factory minimum settings. Some venting configurations may require minor air shutter adjustments for optimum performance. Installation Manual - SRF40 Page 13...
  • Page 14: Plastic Bag Contents And Hardware Pack

    They are standard hardware items and can be purchased at any local hardware store. AA Battery AAA Battery Remote Cover Plate, Battery Box Wire Assembly Rear spacers (for installation Battery Box Wire Grommet Module to Interface with forced air distribution kit) Page 14 Installation Manual - SRF40...
  • Page 15: Dimensions

    103mm 1039mm 2" 10mm 51mm 1 1/4'' (MAX.) 32mm 35 3/4" 909mm 48 7/8" 1 1/2" 1242mm 38mm 18 7/8" 5 1/4" 481mm 133mm © 2021, FABRICANT DE POÊLES INTERNATIONAL INC. TOUS DROITS RESER Installation Manual - SRF40 Page 15...
  • Page 16: Part B - Installation

    4 ¼ inches 4 1/4" clearance must be maintained from the perpendicular 108mm wall and the front opening of the fireplace. 45° Page 16 Installation Manual - SRF40...
  • Page 17: Framing Clearances And Mantle

    WARNING Before building the framing, make sure to remove the glass door latch tool secured to the top of the left side for shipping. This tool is needed to open the glass door. Installation Manual - SRF40 Page 17...
  • Page 18 Four corner supports (such as masonry blocks). These supports must be positioned so they contact all four perimeter edges on the bottom of the unit. 3.3.1 Corner Framing 49 1/2" 1257mm 84 3/8" 2143mm Page 18 Installation Manual - SRF40...
  • Page 19 If the fireplace is installed directly on carpeting, tile or other combustible material other than wood flooring, it should be installed on a metal or wood panel extending the full width and depth of the fireplace. Installation Manual - SRF40 Page 19...
  • Page 20 A vent shall not terminate directly above a sidewalk or paved driveway that is located between two single family dwellings and serves both dwellings. Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor. Page 20 Installation Manual - SRF40...
  • Page 21 FOR 1/2'' THICK FACING MATERIAL FOR 5/8'' THICK FACING MATERIAL Secure fireplace to framing with nailing flanges. Preset depth to suit facing material (1/2" or 5/8" thick). Installation Manual - SRF40 Page 21...
  • Page 22: Finishing

    300 oF minimum sealant material must be used. These joints are not required to be sealed. Only non-combustible material (using 300oF minimum adhesive if needed), can be applied as facing to the fireplace surround. Page 22 Installation Manual - SRF40...
  • Page 23 Draft relief openings must not be covered or blocked. FINISHED WALL (COMBUSTIBLE MATERIAL ALLOWED) NON-COMBUSTIBLE BOARD NON-COMBUSTIBLE BOARD INSTALLED FLUSH TO THE FIREPLACE FACING FINISHED WALL (COMBUSTIBLE MATERIAL ALLOWED) NON-COMBUSTIBLE BOARD NON-COMBUSTIBLE BOARD INSTALLED ON THE FIREPLACE FACING Installation Manual - SRF40 Page 23...
  • Page 24: Installing A Television Above A Fireplace

    If you have a TV above your fireplace, turn off the fireplace and let it cool completely before servicing or touching any buttons on the TV. Do not drive excessively long screws into the face of the unit as internal parts may be damaged. Page 24 Installation Manual - SRF40...
  • Page 25: Venting Installation

    (40' maximum vertical and 18' maximum horizontal) in the vertical or horizontal run. The maximum number of Unacceptable vertical and horizontal vent run. 90° elbows in a vent run is three. See Examples A, B and C. Installation Manual - SRF40 Page 25...
  • Page 26: Damper Adjustment

    To adjust, loosen the Phillips screw and rotate handle towards the left to close. We recommend a 1/3 closed on installations above 30 ft. WARNING Adjust damper for vertically terminated units only. Do not adjust for horizontally terminated units DAMPER Page 26 Installation Manual - SRF40...
  • Page 27: Clearance To Combustibles

    NOTICE: Maintain one inch (1") of clearance around vertical vent pipe. For horizontal vent, maintain a minimum 1 inch clearance to the bottom and sides of the vent, and 3 inch clearance to combustibles above the vent pipe. VENT PIPE 1” MINIMUM CLEARANCE AROUND VENT PIPE Installation Manual - SRF40 Page 27...
  • Page 28: Termination Vent System

    Wall straps must be used to support offset pipe every 4’. This application will require that you first determine the roof pitch and use the appropriate venting components. NO ELBOW 25.4 mm Page 28 Installation Manual - SRF40...
  • Page 29 Example Vent Runs Initial Pipe (Horizontal) A (Vertical) Length Maximum (In Inches) (In Feet) *Maximum horizontal run is 100% of vertical, but cannot exceed 18 feet. Minimum rise of the fireplace is 1 foot. Installation Manual - SRF40 Page 29...
  • Page 30 Reposition the fireplace and vent system, if necessary, to accommodate ceiling joists or obstructions. Cut a 10-5/8 inch x 10-5/8 inch hole through the ceiling, using the center point previously marked. Frame the hole with framing lumber the same size as the ceiling joists. Page 30 Installation Manual - SRF40...
  • Page 31 If the area above the ceiling is an attic, position and secure the firestop on top of the previously framed hole. NOTE: Remove insulation from the framed area in the attic before installing the firestop and/or vent pipes. Installation Manual - SRF40 Page 31...
  • Page 32 Note: Subtract 3 feet from the total horizontal measurement for each 90° elbow installed horizontally. Example Vent Runs Initial Pipe B (Horizontal) A (Vertical) Length Maximum (Dimensions In Inches) Not Allowed 72 (6 ft) 108 (9 ft) Minimum rise of the fireplace is 1 foot. Page 32 Installation Manual - SRF40...
  • Page 33 Secure firestop with nails or screws. The heat shields of the firestops MUST BE placed towards the top of the hole. Continue the vent run through the firestops. 13” WALL FIRESTOP Installation Manual - SRF40 Page 33...
  • Page 34 Ensure the sidewall venting clearances are observed. If venting system is installed below ground, we recommend a window well with adequate and proper drainage to be installed around the termination area. 4.4.8 Typical Basement Installation 15” 381mm Page 34 Installation Manual - SRF40...
  • Page 35: Framing

    (305mm) above the ground level, and top of the cap must be no less than 18 in (457mm) below a combustible projection, and no closer than 9  in (229mm) to any wall running parallel to vent termination. GENERIC MODEL SHOWN Installation Manual - SRF40 Page 35...
  • Page 36 4 3/4 in ALLOWED WITH MINIMUM VERTICAL RISE AND 90 ELBOW 12 in 18 1/2 in 4 3/4 in Corner Installation Vertical, 90o Elbow To Horizontal Out The Wall 49 1/2" 1257mm 84 3/8" 2143mm Page 36 Installation Manual - SRF40...
  • Page 37: Minimum Vent Height Above The Roof

    (including insulation) to the vent system. When installing the vent system in a chase, insulate the chase as you would the outside walls of your home. This is especially important in cold climates. Upon completion of chase framing, install the vent system by following the instructions in this manual. Installation Manual - SRF40 Page 37...
  • Page 38 8’ (2.44M) 45° 4.7.1 Approuved Venting Component The following vent systems are acceptable for use with the SRF40: • Simpson Duravent® GS 5 in - 8 in • American Metal Products 5 in - 8 in • Selkirk Direct-Temp® 5 in - 8 in •...
  • Page 39: Termination Clearances

    Important! When vent termination exits through foundation less than 20 inch (508 mm) below siding outcrop, the vent pipe must extend outward so that the horizontal vent termination is located flush to, or beyond the outcrop siding. Installation Manual - SRF40 Page 39...
  • Page 40: Gas Connections

    Massachusetts requires that a flexible appliance connector cannot exceed three feet in length. Gas Supply Pressure Manifold Pressure (inches w.c.) (inches w.c.) Normal (HI) Minimum Normal Maximum Natural Gas 14.0 Propane Gas 10.8 11.0 14.0 10.0 Page 40 Installation Manual - SRF40...
  • Page 41: Installing A New Shut-Off Valve

    The fireplace must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5 kPa). Installation Manual - SRF40 Page 41...
  • Page 42: Checking Manifold Pressures

    Attach the gas flex line to the pre-installed gas line. Refer to the Gas Supply section in this manual for details on the installation requirements for the gas supply line. Page 42 Installation Manual - SRF40...
  • Page 43: Electrical Connections

    NOTICE: If an auxiliary device is to be used, its wiring may be fed through the junction box strain relief. Auxiliary device amperage limit is 5 amps. NOTICE: A one inch diameter hole should be use to pass wiring through studs. Installation Manual - SRF40 Page 43...
  • Page 44: Control Module Access

    ELECTRICAL POWER TO UNIT JUNCTION BOX / CONTROL MODULE USER INTERFACE/ COMPONENT BATTERY HOLDER ACCESS BOX MUST BE INSTALLED USER INTERFACE INTO WALL JUNCTION VERTICAL HARNESS BOX. (ORANGE LOW- FRAMING VOLTAGE BOX MEMBER RECOMMENDED.) Page 44 Installation Manual - SRF40...
  • Page 45: Wiring Diagram

    Wiring Diagram Installation Manual - SRF40 Page 45...
  • Page 46 Do not cut or remove the grounding prong from this plug. CAUTION Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Page 46 Installation Manual - SRF40...
  • Page 47: Optional Traditional Gravity Hot Air Distribution Kit Installation (Ac04367)

    5/8" MAX. 2" MIN. MAX. 8 3/8" 1" Dimensions of TYP. 213mm 1" the hole to be cut TYP. in the faceplate for the installation of 8 3/8" 213mm the hot air outlet frame Installation Manual - SRF40 Page 47...
  • Page 48 • There must be a minimum 20" (508 mm) clearance between the hot air outlets and a wall in front. 6" MIN. 6" 28 1/4" MIN. NON COMBUSTIBLE MATERIAL AREA MIN. FRAMING HEADER NON-COMBUSTIBLE NON COMBUSTIBLE MATERIAL AREA 20" 508mm MIN. Page 48 Installation Manual - SRF40...
  • Page 49 Screw the 2 anchor plates (E) with the 8 screws provided (F) on the top of the fireplace (4 for each anchor plate). Insert the flexible or rigid conduits (D) (not supplied) into each anchor plate and secure in place with 6 other self-drilling screws provided (G). Installation Manual - SRF40 Page 49...
  • Page 50 (D) into the outlets of the elbows (C). Support the frame behind the non-combustible liner and screw it into place. Screw the frame to the outlet of the elbow (C) using 3 self-drilling screws in each. Secure the decorative grids (A) to the frames with screws. Page 50 Installation Manual - SRF40...
  • Page 51: Optional Modern Gravity Hot Air Distribution Kit Installation Ac04369

    8 1/8" the hole to be cut 40 1/8" in the faceplate for 1020mm the installation of the heat distribution 25" 41 1/16" Dimensions of the decorative plate 42 5/16" 40 3/4" 3" 2 5/16" Installation Manual - SRF40 Page 51...
  • Page 52 There must be a clearance of at least 6" (152 mm) between the frame of the hot air outlet and a side partition or a mantle made of combustible material. 6" 152mm MIN. AC04369 : ENSEMBL D'AIR PAR 6" FRAMING HEADER MIN. NON-COMBUSTIBLE NON COMBUSTIBLE MATERIAL AREA 33 5/8" MIN. 78" MIN. 6" 152mm MIN. Page 52 Installation Manual - SRF40...
  • Page 53 Screw the 2 anchor plates (E) with the 8 screws provided (F) on the top of the fireplace (4 for each anchor plate). Insert the flexible or rigid ducts (D) into each anchor plate and secure in place with 6 other self-drilling screws provided (G). Installation Manual - SRF40 Page 53...
  • Page 54 Secure flexible or rigid ducts (B) to gravity box (C) with self-drilling screws (3 for each telescopic section). Rest the housing on the non-combustible material and secure with 4 screws in the housing. Fix the air circulation plate (D) to the box (C). Page 54 Installation Manual - SRF40...
  • Page 55: Appendix 1: Accessories

    APPENDIx 1: ACCESSORIES The following accessories must be purchased separately. Their installation instructions are included in their kit and can be found on Valcourt website, in the options/Accessories section of this fireplace’s page. Description Code REQUIRED ACCESSORIES Classic Wood Logs Ember and Black Glowing Wool...
  • Page 56 This document is available for free download on the Stove Builder International inc. manufacturer’s website. It is a copyrighted document. 250, rue de Copenhague, Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002...
