Check Equipment; Location; Wall Control - Bryant Evolution Connex Control Installation Instructions Manual

• Wire complete system according to this instruction.
• Setup, commission, and operate system according to this instruction, and as supplemented in
the HVAC equipment Installation Instructions, to assure a smooth and trouble free start-up.
• Note that some detailed equipment configuration and service information may be included
with the equipment instructions. Please refer to the equipment installation instruction
manuals, and applicable technical training materials, for all devices for complete
information.

4.2. Check Equipment

Inspect equipment. File a claim with shipping company prior to installation if shipment is
damaged or incomplete.

4.3. Location

ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal injury or death.
Disconnect power before routing control wiring.
All wiring must comply with national, state, and local codes.

4.3.1. Wall Control

The Evolution Connex Control is the command center for the Evolution System. It should be
located where it is easily accessible and visible to the adult homeowner or end user. For accurate
temperature measurement, the following guidelines should be followed:
The Evolution Connex Control, Remote Room Sensors and Smart Sensors SHOULD be
mounted:
• Approximately 5-ft (1.5 m) from the floor.
• Close to or in a frequently used room, preferably on an inside partitioning wall.
• On a section of wall without pipes or ductwork.
The Evolution Connex Control and Sensors SHOULD NOT be mounted:
• Close to a window, on an outside wall, or next to a door leading to the outside.
• Exposed to direct light or heat from a lamp, sun, fireplace, or other temperature-radiating
objects which could cause a false reading.
• Close to or in direct airflow from supply registers.
• In areas with poor air circulation, such as behind a door or in an alcove.
