■ IC-V82

GENERAL
• Frequency coverage : (unit: MHz)
USA
Europe, Tailand, Korea
General (LM), CSA (LM)
*Guaranteed: 144–148 MHz range only.
• Type of emission : FM
• Number of memory channels : 207 (incl. 6 scan edges and 1 call)
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
• Frequency stability : ±2.5 ppm
• Power supply requirement : 7.2 V DC (6–10.3 V DC acceptable;
• Current drain
(at 7.2 V DC: approx.)
Transmit
Receive
• Antenna connector : BNC
• Dimensions : 54(W) × 139(H) × 36.7(D) mm
(proj. not included)
• Weight (approx.) : 390 g; 13.8 oz
• Ext. data connector : 3-conductor 2.5 (d) mm (
All stated specifications are subject to change without notice or obligation.
Tx: 144–148/Rx: 136–174*
Tx/Rx: 144–146
Tx/Rx: 136–174*
(–10°C to +60°C)
Icom's battery pack only)
:
at 7 W (High) 2.6 A
at 4 W (Middle) 2.0 A
at 0.5 W (Low) 1.0 A
standby 80 mA
power save 30 mA
max. audio 250 mA
(50 Ω)
2 1 ⁄ (W)×5 15 ⁄ (H)×1 7 ⁄ (D) in
8 32 16
(with BP-222N and Ant.)
200 g; 7.1 oz
(without battery pack and Ant.)
1
⁄ ")
10

SPECIFICATIONS

TRANSMITTER
• Modulation system : Variable reactance frequency mod.
• Output power (at 7.2 V) :
[Tailand]
[Other]
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dBc
• Microphone connector : 3-conductor 2.5 (d) mm (
RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 46.35 MHz, 2nd: 450 kHz
• Sensitivity : 0.16 µV typical
(at 12 dB SINAD)
• Squelch sensitivity : 0.11 µV typical
(threshold)
• Selectivity :
[Wide]
[Narrow]
• Spurious and image rejection : 80 dB typical
• Intermodulation : 65 dB typical
• Audio output power : More than 0.3 W
(at 7.2 V DC)
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
15
5.5 W/4 W/0.5 W (High/Mid/Low)
7 W/4 W/0.5 W (High/Mid/Low)
/±2.5 kHz
[Wide] [Narrow]
1
⁄ ")/2.2 kΩ
10
More than 55 dB
More than 50 dB
at 10% distortion with
an 8 Ω load
1
⁄ ")/8 Ω
8
14
15
75
