88 5531 10N
Bedford
Entertainment Credenza
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
F.
Fixed Shelf
1 pc.
G.
Back Panel
1 pc.
J.
Back Panel
Back Panel
1 pc.
N.
Door
1 pc.
Hardware List
Cam Lock Screw
28 pcs.(+1 extra)
Cam Lock
28 pcs.(+1 extra)
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
B.
Side Panel
1 pc
.
H.
Plinth
1 pc.
K.
2 pcs.
O.
P.
Door
Door
1 pc.
1 pc.
Magnet
4 pcs.
Wood Screw
for Magnet
8 pcs.(+1 extra)
servicedesk@homestyles-furniture.com
Casual Attire For Today's Home
D.
Middle Panel
1 pc
.
C.
Side Panel
1 pc.
I.
Base
1 pc.
L.
Shelf
1 pc.
Q.
R.
Door
Back Support
1 pc.
1 pc.
Adjustable Pin
20 pcs.(+1 extra)
Wood Screw
for Back Panel
12 pcs.(+1 extra)
E.
Middle Panel
1 pc
.
M.
Shelf
4 pcs.
S.
Leg
1 pc.
Pull Handle
4 pcs.
Machine Screw
4 pcs.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Homestyles Bedford 88 5531 10N
Summary of Contents for Homestyles Bedford 88 5531 10N
- Page 1 Wood Screw Wood Screw Cam Lock Machine Screw for Magnet for Back Panel 28 pcs.(+1 extra) 4 pcs. 8 pcs.(+1 extra) 12 pcs.(+1 extra) Tools required for assembly : Phillips screwdriver Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319 servicedesk@homestyles-furniture.com...
- Page 2 Assembly Instructions 2/4 Cam Lock Screw STEP 1 Wood Screw Magnet Attach 2X Magnets to Top (A) by using Wood Screws in the pre-drilled holes (See figure 1). Insert Cam Lock Screws into the pre-drilled holes of Top (A). (Figure 1) STEP 2 Insert Cam Lock Screws into the pre-drilled holes...
- Page 3 Assembly Instructions 3/4 Cam Lock Cam Lock Screws STEP 4 Attach Base (I) to the unit with Cam Locks. Put 3X Cam Lock Screws into the pre-drelled holes of Base (I) as shown, then attach Back Support (R) to Base (I) with Cam Locks and attach Side Panel (B) and (C), Plinth (H) to the unit with Cam Locks.
- Page 4 Assembly Instructions 4/4 (Figure 4) (Figure 5) STEP 6 Attach Doors (N), (O), (P) and (Q) by sliding the door lift hinges into the side panels lift hinges. (See figure 4) Assemble Pull Handles to Doors with Machine Screws. (See figure 5) (Figure 6) STEP 7 Insert 12X Wood Screws from the back of the unit,...
