Appendix B - Built-in control programs in a stand-alone Room Controller

This appendix provides the following information for each of the Room Controller's 12
built-in control programs:
• Control schematic
• Point list
• Sequence of operation
The 12 built-in control programs are:
#1 100% outside air unit (page 43)
#2 Air source heat pump - reverse to heat (page 47)
#3 Air source heat pump - reverse to cool (page 51)
#4 Air source heat pump - intermittent fan - reverse to heat (page 55)
#5 Air source heat pump - intermittent fan - reverse to cool (page 58)
#6 Convective/fin tube heater (page 61)
#7 Fan coil unit - 2-speed fan, modulated or 2-stage cooling and heating (page 62)
#8 Fan coil unit - 3-speed fan, 2-stage or modulated cooling, 1-stage or modulated heating
#9 Fan coil unit - 3-speed fan, 1-stage or modulated cooling, 2-stage or modulated heating
#10 Fan coil unit - intermittent fan, modulated or 2-stage cooling and heating (page 74)
#11 Fan coil unit - heat controlled fan, modulated to 2-stage cooling and heating (page 78)
#12 Unit ventilator (page 82)
You can use a BACview
values of certain properties in a built-in control program. See Appendix C - Editing
properties in a built-in control program (page 86).
(page 66)
(page 70)
Handheld or the Virtual BACview application to edit default
