Switch and
The Switch and Jumper Positions page shows the current physical settings on the Room
Controller.
Jumper Positions

Display Options

The Display Options page shows the current selections for the information displayed in
the RC642D Room Controller. On this page, you can choose to have:
•
•
NOTE You can also change the format on the RC642D.
1
2

To communicate through the local access port

Using a computer and a USB Link Kit, you can communicate locally with the Room
Controller to download or to troubleshoot.
PREREQUISITES
•
•
•
•
CAUTION If multiple controllers share power but polarity was not maintained when they
were wired, the difference between the controller's ground and the computer's AC power
ground could damage the USB Link Kit and the controller. If you are not sure of the wiring
polarity, use a USB isolator between the computer and the USB Link Kit. Purchase a USB
isolator online from a third-party manufacturer.
Time displayed as 12 Hour or 24 Hour format
Date displayed as MM-DD or DD MM format
Tap the TIME button until the display shows the item whose format you want to
change, then hold down the TIME button.
While holding down the button, tap
A computer with a USB port
A USB Link Kit. See the USB Link Kit Technical Instructions
(http://accounts.automatedlogic.com/download).
NOTE The USB Link Kit driver is installed with WebCTRL v5. But if needed, you can
get the latest driver from http://accounts.automatedlogic.com/download. Install the
driver before you connect the USB Link Kit to your computer.
v2.09.320 or later controller driver
Room Controller is set for network operation (DIP switch 8 is Off).
or to select a different format.
23
