Recipient Device Object
Identifier
Process Identifier
Issue Confirmed
Notifications

Calendars

Calendars are provided in the driver for BACnet compatibility only. Use WebCTRL's
Schedules feature instead.
Common and
On these pages, you can enable/disable, change BACnet alarm properties, or set delays
for the following BACnet alarms:
Specific Alarms
Common alarms:
•
•
•
•
•
•
•
NOTE To set up alarm actions for controller generated alarms, see Setting up alarm
actions in WebCTRL Help.
Module Generated Alarm
Description
Events
Alarm Category and
Alarm Template
Enable
Notification Class
Custom
You can set up a translation table that an analog input will use to translate the raw data
from a non-linear sensor to the engineering units you want it to output on the wire. In the
Translation
NET tree, select Custom Translation Table #1, #2, or #3. The Properties page has
Tables
instructions. For the input to use the translation table, navigate to the input in WebCTRL's
GEO tree, select the Details tab, then set Sensor Type (Scaling Method) to Non-Linear,
Custom Table #__.
Module Halted
All Programs Stopped
Duplicate Address
Locked I/O
Control Program
Program Stopped
Excessive COV
Type the Device Instance from SiteBuilder (or from the
network administrator for third-party devices) in the # field.
Change for third-party devices that use a BACnet Process
Identifier other than 1. WebCTRL processes alarms for any
32-bit Process Identifier.
Select to have a device continue sending an alarm
message until it receives delivery confirmation from the
recipient.
Specific alarm:
•
Low Battery Alarm
Short message shown on WebCTRL's Alarm page or in an
alarm action when this type of alarm is generated.
See Customizing alarms in WebCTRL Help.
Clear these checkboxes to disable Alarm or Return to
normal messages of this type from this controller.
Do not change this field.
