Automated Logic RC642 Technical Instructions page 38

To use this
control program... With these features...
•
Fan coil unit –
•
3-speed fan,
1-stage or
•
modulated cooling,
2-stage or
•
modulated heating
•
•
•
•
•
Fan coil unit –
•
intermittent fan,
modulated or
•
2-stage cooling and
heating
•
•
•
•
•
•
Fan coil unit – heat
•
controlled fan,
modulated or 2-
•
stage cooling and
heating
•
•
•
•
•
Scheduled operation
Freeze protection (optional) – Requires
sensor
Smoke detection (optional) – Requires
sensor
3-speed speed fan
Modulating chilled water valve (analog) OR
1-stage cooling
Modulating hot water valve (analog)
2-stage heating
Fan status monitor (optional) – Requires
sensor
Discharge temperature limit control (optional)
– Requires sensor
Scheduled operation
Freeze protection (optional) – Requires
sensor
Smoke detection (optional) – Requires
sensor
Single-speed fan – Cycles on and off with
heating or cooling
Modulating chilled water valve (analog) OR
2-stage cooling
Modulating hot water valve (analog)
2-stage heating
Fan status monitor (optional) – Requires
sensor
Discharge temperature limit control (optional)
– Requires sensor
Scheduled operation
Freeze protection (optional) – Requires
sensor
Smoke detection (optional) – Requires
sensor
Single-speed fan – Cycles on and off with
cooling; fan is controlled by heating coil
during heating
Modulating chilled water valve (analog) OR
2-stage cooling
Modulating hot water valve (analog)
2-stage heating
Fan status monitor (optional) – Requires
sensor
Discharge temperature limit control (optional)
– Requires sensor
34
Set the rotary
switches to...
09
OR
10
OR
11
OR
