RGBlink RGB-RD-UM-M2 E003 User Manual page 43

When <Two Inputs Two Outputs> is selected, [A] and [B] are background layers, [C] and [D] are
sublayers.
In the right mode, when <One Input Two Outputs> is selected, [A] is the background layer, [C] is
the sublayer, [B] and [D] have no function.
When <Two Inputs Two Outputs> is selected, [A] and [B] are background layers, [C] is the sublayer,
and [D] has no function.
2. Overlayer
(1) Press the MENU button and enter to the menu items. Turn the knob and select <Output>:
->Output
(2) Press the knob to confirm. Turn the knob, select <4K1K> under <System Mode>, press the
knob to confirm:
->4K1K
(3) Select <Overlayer>, press the knob to confirm:
Input
Background
Advance
Normal
4K2K
Matrix
Chapter 3: Using Your Product
>>
>>
>>
>>
>>
>>
>>
>>
37
