1.2

Product Features

1.2.1

General


CPU: Intel

System Chipset: Intel

BIOS: AMI 16 Mbit Flash BIOS

System Memory: One DDR3L SODIMM. DDR3L 1333MHz up to 8 GB

Watchdog Timer: Single chip Watchdog 255-level interval timer, setup by soft-
ware

I/O Interface: 2 x RS232, 6 x RS232/422/485

USB: 5 x USB 2.0, 1 x USB 3.0, 1 x internal USB 2.0 for security dongle

Audio: High Definition Audio (HD), Line-in, Line out, Mic-in

Storage: 1 x mSATA and 1 x high capacity 2.5" SATA HDD (up to 12.5mm
height)

Expansion Interface:
– Supports 2 x Full Size MiniPCIe (1 with SIM holder)

Software API: Advantech iManager/SUSI 4.0 and SUSIAccess - Remote
Device Management technology
1.2.2

Display


Controller: Intel

Resolution:
– VGA: Supports up to 2048 x 1152
– HDMI: Supports up to 1080P @ 60Hz,Supports HDMI 1.4a

Dual Display: VGA+HDMI
1.2.3

Ethernet



Chipset:

– LAN1 Intel i210
– LAN2 Intel i210

Speed: 1000 Mbps

Interface: 2 x RJ45

Standard: Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3y,
IEEE 802.ab.
1.3 Chipset
1.3.1

Functional Specification

1.3.1.1 Processor
Processor
Memory
®
Celeron™ Processor J1900 2.0GHz
®
Celeron J1900 SOC
®
Celeron J1900
®
Intel Celeron™
Processor J1900
®
Intel Celeron™
J1900 at 2.0GHz, with 2MB L2 Cache Manufacturing
Technology 22nm
Supports DDR3L 1333MHz up to 8GB
1 x 204-pin SODIMM socket type
3 ARK-2121F User Manual
