Technical data

Welding torch cooling unit

Technical data
8
8.1 Welding torch cooling unit
Technical data limit values
The limit values determination from technical data is calculated taking account of the combined
system as a whole (cooling unit and welding machine).
cool
Supply voltage (from power source)
Mains frequency
Cooling capacity
Max. flow rate
Max. coolant outlet pressure
Max. tank capacity
Cooling mode/protection
classification
Coolant
Ambient temperature
EMC class
Safety identification
Harmonised standards used
Dimensions L/W/H
Weight (without coolant)
1
Ambient temperature dependent on coolant! Observe the coolant temperature range of the coolant!
24
82 U44
50/60 Hz
1600 W (1 l/min.)
5 l/min.
3.5 bar
Approx. 7 l
F/IP 23
> see 5.2.3.1 chapter
–25 °C to 40 °C
see declaration of conformity (machine documentation)
730 x 370 x 294 mm
28.7 x 14.6 x 11.6 inch
24 kg
52.9 lb
82 U45
230 V
1600 W (1 l/min.)
1800 W (2 l/min.)
20 l/min.
4.5 bar
Approx. 7 l
1
A
/
27.5 kg
60.6 lb
099-008268-EW501
29.06.2017
