Design and function
5
Risk of injury from electric shock!
Contact with live parts, e.g. welding current sockets, is potentially fatal!
•
Follow safety instructions on the opening pages of the operating instructions.
•
Commissioning may only be carried out by persons who have the relevant expertise of
working with arc welding machines!
•
Connection and welding leads (e.g. electrode holder, welding torch, workpiece lead,
interfaces) may only be connected when the machine is switched off!
Read and observe the documentation to all system and accessory components!
5.1
Assembly/disassembly
Improperly secured equipment!
Equipment, equipment combinations and accessories incorrectly fastened onto
transport systems can tip over during transport and cause injuries!
•
Only used the original parts supplied to fasten the equipment.
•
Use the systems only for transporting the machines > see 3.1.1 chapter.
•
Check the fixing points before each transport and at regular intervals.
Risk of accidents due to supply lines!
During transport, attached supply lines (mains leads, control cables, etc.) can cause
risks, e.g. by causing connected machines to tip over and injure persons!
•
Disconnect all supply lines before transport!
5.1.1
Preparations
Item Symbol
1
2
•
Remove threaded grooved pins, M5 x 16
The screws will be needed again for mounting.
099-008268-EW501
29.06.2017
Description
0
Cooling unit
Threaded grooved pin
M5 x 16 mm
Design and function
WARNING
CAUTION
Figure 5-1
Assembly/disassembly
11
