Installation
Mounting Controller
The provided Sway Command controller module (Fig. 1) will be fitted within 152 mm (6 inches) of the
centerline of the chassis, and to the right side of the center rail on the chassis, at the front of the chassis
frame (Fig. 2A).
The controller must be mounted in a level condition, centered on the crossmember, and according to the
orientation arrow on the label (Fig. 4A).
Note: The controller MUST be mounted facing the rear of the caravan (Fig. 2). The controller will not
operate correctly if mounted improperly.
Rev: 10.15.20
A
Fig. 1
Fig. 2
Page 4
CCD-0003688
