Introduction
Safety
Resources Required
Installation
Mounting Controller
Sway Command Wiring
Sway Command Light Pod Mounting
Testing the System
Light Codes and Troubleshooting
Notes

Introduction

The Sway Command® system is a self-contained caravan stability control module that detects undesirable
caravan movement from external sensors and mitigates it by adaptively applying a variable braking voltage
to the left and right caravan electric brakes.
The Sway Command® system uses sensors to detect excessive caravan sway. The system activates
automatically and applies voltage proportional to the amount of sway detected to the electric caravan
brakes. This dampens the sway and slows the caravan down. When excessive sway is detected, the light pod
will blink red and the tow vehicle operator may feel the caravan brakes activate until the sway is dampened.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/sway-command-by-trailair.
Note: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.

Safety

Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage,
including voiding of the LCI limited warranty.
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause
death or serious personal injury and/or severe product and property damage, including voiding
of the component warranty, if not performed safely and within the parameters set forth in
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
Rev: 10.15.20

TABLE OF CONTENTS

this manual.
Page 2
2
2
3
4
4
6
6
7
8
9
CCD-0003688
