- Page 1 OneControl HVAC Control 2.0 ® OEM INSTALLATION MANUAL Rev: 11.09.20...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Compatability Specifications Safety Resources Required Preparation Prior to Installation Connections Installation Controller Harness Connections Zone Sensor Installation Operation Power On/Off Touch Panel Adjusting HVAC Control Wiring Diagram Notes Introduction The OneControl® Touch Panel (OCTP) (formerly MyRV®) is a compatible touchscreen device that provides system controls and monitoring software for the recreational vehicle unit. -
Page 3: Specifications
Specifications The HVAC control system includes a "capabilities" switch which must be set to correspond with the attached equipment. The switch settings are as follows: Switch Function When "OFF" When "ON" Note Dual-Speed Fan Fan is high-speed only Fan has a low-speed wire Heat Pump (HP) System (if present) A/C only Rooftop A/C System includes HP... -
Page 4: Preparation
Preparation Prior to Installation NOTE: Make sure the control capabilities have been configured before the HVAC controller is mounted. NOTE: The HVAC controller should be in close proximity to any other OneControl controllers. All thermostat control leads should be run from the heating and cooling appliances to this centralized location. - Page 5 Connect to DC 12V power using the main power harness (Fig.3). Fig. 3 NOTE: The controller draws a relatively low amount of current. Power and ground can be obtained from another nearby module. Using the 6-pin wire harness and wire diagram included, connect the outputs from the controller to the appropriate inputs on the air conditioning, heat pump or furnace (Fig.1D,1E).
-
Page 6: Harness Connections
Harness Connections Generator connections to the HVAC thermostat control (Fig. 5A, 6A) are via the 6-pin connector (Fig. 5B, 6B). When wired into the "running signal" of the generator, the system tracks the total running hours of the generator, and can be programmed to display an alert when the generator is due for scheduled maintenance. NOTE: The controller implements an automatic priming cycle at the beginning of the startup sequence. -
Page 7: Zone Sensor Installation
Zone Sensor Installation The OneControl Zone Sensor Kit consists of a sensor with cable, a cable hold-down clamp, and a sensor cover. The kit is for use exclusively with OneControl thermostats and climate control systems. A sensor must be installed in each of the climate zones to be controlled. Each climate zone requires at least one temperature sensor to be connected between the blue with stripe "Sensor Power"... -
Page 8: Operation
Operation Adhere to all local and national codes. Disconnect all external A/C power to the unit before installing, removing, or cleaning. All user control and input is accomplished using the OneControl mobile application, OneControl tablet or OneControl Touch Panel (OCTP). NOTE: When using the HVAC system, all of the controls you would normally find on your thermostat will be located in the HVAC icon on your OneControl Touch Panel. -
Page 9: Adjusting Hvac Control
Adjusting HVAC Control In the touch panel home screen, select the HVAC icon to open the app (Fig. 12A). In the HVAC menu screen, select the Climate Zone you wish to adjust (Fig. 13). There are two boxes on the left hand side of the screen (Fig. 14). The top box controls the heating/ cooling mode. - Page 10 C. Press the bottom of the two boxes on the right. A large box will populate with all available fan settings (Fig. 15). Choose from the following: High – The high fan will run continuously until another setting is chosen II.
-
Page 11: Wiring Diagram
Wiring Diagram The following wiring diagrams show possible appliance connections, depending on the OEM installed controller. OneControl® HVAC Triple Zone Wiring Diagram for: Furnace, A/C, Heat Pump, Dual Speed Fan Fig. 18 Zone Connector (715845 Controller) OEM will connect red common wire Generator 8 7 6 5 to 12v+ or 12v- (ground) depending... - Page 12 OneControl® HVAC Dual Zone Wiring Diagram for: Furnace, A/C, Heat Pump, Dual Speed Fan Fig. 19 Generator Zone Connector (406350 Controller) (optional) 1 7 2 8 3 9 4 10 5 11 6 12 Breaker Box 1 2 3 4 5 6 THERM 12V to Zone THERM...
-
Page 13: Notes
Notes Page 13 Rev: 11.09.20 CCD-0001450... - Page 14 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
