MULTI-FUNCTION WIRELESS CONTROLLER
OPERATION AND PROGRAMMING INSTRUCTIONS
Operation
1.
Locate the LCI Wireless Remote and press the silver
"Home" button to begin.
2.
When the keypad appears on the screen, enter the
4-digit PIN by pressing the corresponding numbers
on the touch screen (Fig. 1).
Menu Screen Options
1.
The menu screen will show the first four function
options. Select one or press the "Next" button for
more options (Fig. 2).
2.
To return to previous menu screen press the "Prev"
button (Fig. 3).
Rev: 09.14.2016
ELECTRONICS
PREV
Button
Page 1
Fig. 1
HOME
Button
Fig. 2
Fig. 3
NEXT
Button
TI-200
Advertisement
Related Manuals for Lippert Components TI-200
Summary of Contents for Lippert Components TI-200
- Page 1 The menu screen will show the first four function options. Select one or press the “Next” button for more options (Fig. 2). Fig. 3 PREV Button To return to previous menu screen press the “Prev” button (Fig. 3). Page 1 Rev: 09.14.2016 TI-200...
- Page 2 SELECT button (Fig. 8). Repeat steps for all functions to be used. For any function that will NOT be used, select the NONE title option then press SELECT. Page 2 Page 3 Rev: 09.14.2016 TI-200 Rev: 09.14.2016 TI-200...
- Page 3 The multi-function board will “click” when the function titles have been transmitted properly (Fig. 13). NOTE: Contact OEM for fuse assignment procedure. To be performed by authorized RV Technician only. Page 4 Page 5 Rev: 09.14.2016 TI-200 Rev: 09.14.2016 TI-200...
- Page 4 (574) 537-8900 or by email at customerservice@lci1.com. Self-help tips, technical documents, product videos and a training class schedule are available at www.lci1.com or by downloading the MyLCI app. Page 6 Rev: 09.14.2016 TI-200...
