Resources Required - Lippert Components Sway Command Installation Manual

Do not submerge the caravan. The Sway command is not designed to be submerged under water
(Water Crossing). Extended submersion could cause Non-Warrantable damage.
The "CAUTION" symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
Never drill into the Sway Command controller or compromise the pressure equalizer plug hole on
the back of the controller. Doing so voids the warranty and could damage the controller.
The Sway Command controller is water-resistant, but not waterproof. Do not spray high pressure
All electrical wiring harnesses shall be loomed and secured to prevent possible damage and

Resources Required

• Cordless or electric drill or screw gun
• Drive socket for a #14 hex self-drilling screw
• 5.5 mm drill bit
• Impact driver
• Torque wrench (Nm)
• Looming material
• Black saddle
Rev: 10.15.20
in this manual.
shield, depending on the nature of the task.
water directly at the controller.
installed in accordance with best shop practices.
Page 3
• #14 - 10 x 25 mm hex self-drilling screw
(corrosion resistant) (4)
• M6 x 11.0 x 0.7 external serrated washer (4)
• M8 x 25 mm square head wood screws (2)
• M8 x 18 x 12 mm self-drilling pan head screws (2)
• Paint marker/grease pencil
• EOL Vehicle Simulator box
CCD-0003688
