Specifications
The HVAC control system includes a "capabilities" switch which must be set to correspond with the attached
equipment. The switch settings are as follows:
Switch Function
Dual-Speed Fan
Heat Pump (HP)
Air Conditioning
LP Gas Heat
Safety
Ensure that power is properly disconnected at the supply (mains and/or battery). Failure to do so
may result in damage to the product and personal injury or death.
Failure to follow the instructions provided in this manual may result in death, serious injury, unit
This thermostat control device requires 12V direct current (DC), and cannot operate from
alternating current (AC) sources. Confirm that your furnace or air conditioning unit supplies 12V
DC to the zone wiring harness before proceeding. Connecting the thermostat to AC will cause
Ground connections need to be tied together for ALL heating and cooling appliances in a zone.
NOTE: The thermostat module requires 12V DC power from two separate sources:
1.
Power from the house battery should be applied via the main power input connector (PWR)
2.
Each active climate zone HVAC unit will supply its own power to its corresponding thermostat zone
connector.
Resources Required
• Cordless or electric drill or screw gun
• Appropriate drill bits
• Appropriate drive bits
• Tape measure
• Phillips head screwdriver
Rev: 11.09.20
When "OFF"
Fan is high-speed only
System (if present) A/C only
No A/C system in this zone
No gas furnace installed
damage, or voiding of the component warranty.
irreparable damage, and void the warranty.
When "ON"
Fan has a low-speed wire
Rooftop A/C System includes HP
This zone has A/C
Gas furnace installed
Page 3
Note
N/A
Orange wire
HP setting ignored
Furnace has own fan
CCD-0001450
