Initial Start; A/C System - Webasto Sprinter Vancouver Standard Manual

Initial Start

4
Item Part Number
Number
8 5011556A
19 5013253A
44 21499
40 5011487
32 5001085A
33 620406Z
20 5011928
41 5011593
3 6290321660B
2 62U003AA093
4

A/C System:

24. Insulate the low-pressure A/C hose with insulating hose (8) as needed.
b
25. Using anti-condensation tape (19), wrap the TXV valve.
b
26. Using P-clips (44, 40, 32, 33), cable ties and self-tapping screws, secure the hoses and wiring to prevent
chaffing or damage.
4
Recharge the vehicle per the manufacturer's procedures using the chart below.
Item
Lubricant
Refrigerant
4
27. Install the 10 amp fuse in the fuse holders.
28. Start the engine. Test the A/C system for functionality and performance.
4
29. Reinstall all interior panels and components that were removed unless otherwise instructed in this manual.
4
30. Place the new refrigerant label (20) on the radiator core support.
XXX
31. Using two black self-tapping screws (41), install the diffuser (3) on the front of the Vancouver unit.
4
NOTE: This step is optional.
32. Install the Vancouver cover as needed (2).
It is recommended to register your product at
http://www.techwebasto.com/serial/index.php
Description
INSULATION HOSE ID 0.875IN X 6FT LONG
ANTI-CONDENSATION TAPE
TUBE CLAMP
SCREW SELF-DIRLLING - 0.25 X 1 in.
CABLE TIE - HEAVY DUTY BLACK
CABLE TIE 11 IN.- BLACK
LABEL - REFRIGERANT
SCREW 4.2 X 16MM SELF-DRILLING - BLACK
DIFFUSER
AIR DUCT END PIECE
Type
Manufacturer's specification
Manufacturer's specification
.
29
1
As Needed
As Needed
As Needed
As needed
As needed
1
2
1
1
Quantity
4 additional ounces
3.2 lbs.
Sprinter
Quantity
