Operating Instructions

Sunroof:
Doc.-No.:
Date:

Operating the sunroof

1. Control panels (electric and electronic versions)

Electric versions

Hollandia 300 DeLuxe versions without sliding sunshade
(with or without sunrollo), Hollandia 500 FreeDome
Open
Full electronic versions
Hollandia 500 and Hollandia 300 DeLuxe versions without
sliding sunshade, with or without sunrollo
Pre-set position 1
Pre-set position 2
Tilt / slide open
Note: pictures shown in this manual refer to Hollandia 300 DeLuxe Medium, if not stated otherwise. Therefore
minor details in pictures can vary from your sunroof.
Technical Sales Support Webasto International
Hollandia 300, 500, 600, 700, 710
0912033A
20-04-2004
Hollandia 600, Hollandia 300 Classic and
Hollandia 300 DeLuxe versions with sliding
Close
Hollandia 700 and Hollandia 300 DeLuxe
versions with sliding sunshade
Slide close
One touch close
sunshade
Page 1 of 15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hollandia 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Webasto Hollandia 300

  • Page 1: Operating Instructions

    Pre-set position 2 One touch close Tilt / slide open Note: pictures shown in this manual refer to Hollandia 300 DeLuxe Medium, if not stated otherwise. Therefore minor details in pictures can vary from your sunroof. Technical Sales Support Webasto International...
  • Page 2 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 2. Operating manual versions Opening sunroof. Closing sunroof. Technical Sales Support Webasto International Page 2 of 15...
  • Page 3 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 Operating electric versions Switch on ignition. Press -button to open sunroof. Release button when sunroof is in position you like. Maximum tilt position Maximum sliding position Technical Sales Support Webasto International...
  • Page 4 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 Closing completely. Technical Sales Support Webasto International Page 4 of 15...
  • Page 5 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 3. Operating full electronic versions 3.1. Programming the sunroof before using it the first time Switch on ignition. Close sunroof completely, release switch, press again and hold -button for at least 5 seconds.
  • Page 6 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 3. 2. Opening of the sunroof Opening sunroof into sliding position: With ignition switched on, press -button shortly. Press -button shortly again when glass panel reached desired position.
  • Page 7 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 3.3. Closing of sunroof When pressing -button shortly, panel will close completely. Pressing -button shortly again will stop panel. © When pressing briefly -button panel will close from any panel position.
  • Page 8 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 3.4. Programming two pre-set positions Place panel in first favoured position. Press -button for three seconds to store this position under -button. A beep will confirm programming.
  • Page 9 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 3.5. Auto close Switch off ignition. Sunroof beeps once to indicate that panel closes after three seconds. Panel closes. You hear 2 beeps. For preventing roof from closing automatically, press -button briefly within 3 seconds after switching off ignition.
  • Page 10 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 3.6. Jamming protection When closing sunroof……. …….sunroof opens automatically when panel encounters an obstacle. When obstacle is removed, panel will close again. Jamming protection can be switched off by operating button continuously even when ignition is off.
  • Page 11 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 4. Annotations for electric and full electronic versions 4.1. Operation of sunshade Sunshade can be placed in every position. Do not close sunshade completely at >50 km/h and open sunroof (vibrations!). Leave gap of >3cm.
  • Page 12 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 4.2. Special notes Do not open sunroof when it is raining. Drive for at least 5 minutes to dry glass panel before opening. When raindrops are removed from glass panel you can open sunroof.
  • Page 13 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 4.3. Maintenance Clean glass panel with glass cleaner. Do not use scratching substances! Clean rubber seal with wet cloth at least every half year. Apply talcum powder to seal to keep rubber flexible.
  • Page 14 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 Check seal when sunroof leaks. Clean seal with a wet cloth. Apply talcum powder. Contact your nearest Webasto-dealer for service, if sunroof still leaks. Technical Sales Support Webasto International...
  • Page 15 Operating Instructions Sunroof: Hollandia 300, 500, 600, 700, 710 Doc.-No.: 0912033A Date: 20-04-2004 4.4. Malfunctioning If sunroof does not work at all, check fuse. Electronic sunroofs: If sunroof is not working properly, re-program sunroof (see chapter 3.1). Check again correct functioning of sunroof.
